4 Power Tool Description
4.1 Device Views, Important Operating, And Function Parts
1. Cutoff wheel 17. Stop dial / one-touch stop button
2. Wheel guard 18. Fuel tank cap
3. Handle for wheel guard adjustment 19. Oil tank cap, green
4. Top handle 20. Primer
5. Guard 21. Decompression valve
6. Rear handle 22. Idle stop screw “T”
7. Twin-pipe intake openings 23. Carburetor adjustment screws “L” and “H”
(for trained service technicians only)
9. Throttle control lock 24. Water coupling connection (wet cutting)
10. Throttle control 25. Mufer(exhaust)
11. Cutoff wheel attachment screw 26. Standing base
12. Cutoff wheel blockage opening 27. Screenltercouplingadapterofthewatersupply
line
13. Ribbed belt tensioning screw 28. Valve lever for water supply
14. Ribbed belt cover 29. Vibration dial
15. Type plate 30. Water supply line (wet cutting)
16. Starter handle 31. Starter and fan housing with cooling air openings
1
2
4
5
6
9
10
12
13
14
15
17
24
26
27
28
29
30
3
12 SENCORE S8100 CUT-OFF SAW MANUAL
