When the decompression valve (21) is depressed, the
compression pressure in the combustion chamber
is reduced. This means that the engine offers less
resistance during start-up, which makes it noticeably
easier to start the engine.
Starting process: Chap. 6.1, page 22
The decompression valve is closed automatically when
the motor is running.
If you need to pull the starter handle (16) more than once
to start the engine (e.g. during a cold start), you do not
need to depress the decompression valve again.
Decompression valve (21)
4.6 Technical Specication Data
1
In determining the above mentioned values regarding the acceleration of vibrations and sound, the different operating conditions were weighted in accordance with the current standards.
2
Insecurity K purs. to EC directive 2006/42/EC: 2.5 dB(A)
3
Insecurity K purs. to EC directive 2006/42/EC: 2 m/s2 [78.7 "/s2]
Model Sencore S8100
Motor
Single-cylindertwo-strokemotor,four-channelushing
Engine capacity 81 cm
3
[4.94 cu.in]
Bore Ø / stroke 52 mm / 38 mm [2.0” / 1.5”]
Max. power at RPM 4.0 kW / 9,300
1
/
min
[5.36 HP / 9,300 RPM]
Max. torque at RPM 4.8 Nm / 7,000
1
/
min
[3.54 ft·lbf / 7,000 RPM]
Max. permissible speed (9,500 ±200)
1
/
min
[(9,500 ±200) RPM] (no load with cutoff wheel)
Idling speed (2,600 ±200)
1
/
min
[(2,600 ±200) RPM]
Clutch engagement speed (4,000 ±200)
1
/
min
[(4,000 ±200) RPM]
Fuel tank capacity 0.9 l [30 oz]
Oil tank capacity 0.32 l [10.8 oz]
Fuel mix ratio gasoline:oil 50:1
Electronically controlled separate lubrication
ü
Fuel consumption at max. power (ISO 7293)
1.75 kg/h [3.86 lbs/h]
Specicconsumptionatmax.power(ISO7293) 460 g/kWh [0.76 lbs/HP·h]
Carburetor, with primer Position-independent, electronically controlled
Airlter Paper
Ignition Electronic digital ignition with index
Cutoff wheel: Diameter
Bore diameter
Tightening torque of the attachment screw
14”
20 mm or 1”
(30 ±2) Nm [22.1 ±1.48 ft·lbf]
Minimumangeouterdiameter 100 mm [3.9”]
Spindle diameter 20 mm [0.787”]
Maximum spindle RPM 4,550
1
/
min
[4,550 RPM]
Cutting depth, max. 125 mm [4.9”]
Dimensions: height / width / length 430 mm / 267 mm / 775 mm [16.9” / 10.5” / 30.5”]
Weight without tank content and without cutoff wheel
10.5 kg [23.1 lbs]
Sound level
1,2
L
Peq
(EN ISO 19432 Annex B) 98 dB(A)
Sound power level
1,2
L
Weq
(EN ISO 19432 Annex B) 108 dB(A)
Weighted effective acceleration
1,3
a
hv,eq
(EN ISO 19432 Annex C): rear handle / top handle
4.5 m/s
2
/ 6.0 m/s
2
[177 “/s
2
/ 236 “/s
2
]
16
21
SENCORE S8100 CUT-OFF SAW MANUAL 15
