8.2 Cleaning the screen lter Insert of the connection piece
Theconnectionpieceforthewatersupplylineforwetcuttingisequippedwithascreenlterinserttopreventclosureof
the water supply line by contamination in the supplied water.
Water connection for wet cutting:  Chap. 5.7, page 19
Ataweeklyintervalorwhen there is nolongerenoughwatersuppliedforwetcutting,thescreenlter insert of the
connection piece must be removed as follows and cleaned thoroughly:
Danger of contamination for the water supply line!
Only open the water connection in a clean environment.
• Switch off the engine and turn the stop dial
to “0”.
Switching off the engine:  Chap. 6.4, page 23•
Remove the connection of the water supply
line. For this, remove the coupling connection
(24)fromthescreenlterconnectionpiece(27)
of the water supply line in the direction of the
arrow.
•Turnoutscreenlterconnectionpiecewith
suitable open-faced spanner from connection
(a) of the water supply line.
• Disassemble screenlterconnectionpiece
(27) with suitable open-faced spanner.
•Removescreenlterinsert(c)fromscreen
lterreceptacle(d)oftheconnectionpiece.
•Removeseal(b)fromthescreenlterinsert.
•  Flush the screen lter insert, the coupling
connection, both parts of the screen lter
connection piece and the seal with clean water
until all residue of contamination has been
removed.
•  Push the seal (b) again on the screen lter
insert.
•Re-insertthescreenlterinsertwiththeseal
(b) in the screen lter receptacle (d) of the
connection piece in the correct direction (see
gure).
•   Screw together the screen lter coupling
piece.
•Screwthescreenltercouplingpieceintothe
connection (a) of the water supply line again.
• Push on the coupling connection again.
8.3 Idle/ Carburetor Adjustment
The cut off wheel must not rotate when idling!
The idle position must be inspected every time when taking up work and corrected if required.
24
a
27
28 SENCORE S8100 CUT-OFF SAW MANUAL
