PRODUCT INSTRUCTION MANUAL
Page 17 of 29
Part 7 Settings (cont.)
7.8 WASH Alarm -
Set the automatic starting time and turno time of the washing function. If any value is set to be 0, the
transmitter will automatically stop this function.
Enter
Enter
GO TO “Analog output 1 (pH/ORP)”SETUP
SECTION 7.9
Mode
OR
To Set Start of Washing
(unit = seconds)
Enter
Press "ENTER" to conrm choice
Mode
OR
To Set Start o time of
Washing (unit = hours)
Enter
Press "ENTER" to conrm choice
Mode
OR
To Set current loop output and
relay hysteresis (unit = seconds)
Enter
Press "ENTER" to conrm choice
Press "MODE" or
"RIGHT ARROW" to
test WASH light
Mode
OR
Choose “ON”, “WASH”
will light up
Form: INSTRTX3000-Rev A
FIG 7-7
OR PRESS "SET-UP" KEY
TO RETURN TO
MEASUREMENT MODE
To Next Page
