Sensorex TX3000 - Default Chapter; Table of Contents

Table of Contents
1. Specications 1
2. Precautions for installation 2
3. Assembly and installation
3.1 Transmitter installation 2
3.2 Cable set-up 3
4. Overview of TX3000 pH/ORP transmitter
4.1 Illustration of rear panel 4
4.2 Illustration of terminal function 5
5. Conguration
5.1 Illustration of front panel 6
5.2 Function Key Description 7
5.3 LED indicators 8
5.4 Display icons 9
6. Operation
6.1 Measurement mode 10
6.2 Set-up mode 10
6.3 Calibration mode 10
6.4 Reset 10
6.4.1 Master reset 10
6.4.2 Calibration reset 10
7. Settings
7.1 Entry into set-up mode 11
7.2 Security code settings 11
7.3 Measurement parameters 12
7.4 Temperature Settings 13
7.5 Stand by Mode 14
7.6 Hi Alarm Relay 15
7.7 Lo point Alarm Relay 16
7.8 Wash time Relay 17
7.9 Analog output 1 (pH/ORP) 18
7.10 Analog output 2 (temperature) 19
7.11 Sample average of measurements (Digital Filter) 20
7.12 Backlit LCD 21
8. Calibration
8.1 Security code of calibration 22
8.1.2 Setting Code 22
8.2 Entry of calibration mode 22
8.3 Any Buer calibration (2-point) 23
8.4 Calibration of pre-set TECH. buer (Ct1) 24
8.5 Calibration of pre-set NIST. buer (Cn1) 26
Form: INSTRTX3000-Rev A
PRODUCT INSTRUCTION MANUAL
