METIS M308 / M309 / M313 / M316 / M318 / M323 / H309 / H316 / H318 (12-pin)
Communication via Serial Interface / Interface Commands
60
Com-
mand
Parameter
Description / Settings
aa
(aaX)
XY
Output of analog output 2
X=2 (analog output 2); Y=0...8, output temperature or controller
Y=0 = No output Y=6 = manipulated variable (devices with PID controller)
Y=5 = Measured temperature Y=8 = Device temperature
ar
X
Analog output 2
X=0...1; 0=020mA; 1=420mA
as
X
Analog output 1
X=0...1; 0=020mA; 1=420mA
bn
Reference number pyrometer (18-digit ASCII)
bn1
Reference number pyrometer (21-digit ASCII)
bum
XX
Buffer mode selection (XX = 00...02)
bup
Poll of the buffer data (only one current packet!)
Buffer mode 00: answer: AAAA
AAAA = Measured temperature (0xF001 => Overflow)
Buffer mode 01: answer: AAAABBBBCCCC
AAAA = Measured temperature (0xF001 => Overflow)
BBBB = ffff
CCCC = ffff
Buffer mode 02: answer: AAAABBBBCCCCDDDDEEEEFFFFGGHHIIJJ
AAAA = Measured temperature (0xF001 => Overflow)
BBBB = ffff
CCCC = ffff
DDDD = Setpoint value at ramp function (current ramp setpoint value!)
EEEE = (Analog) control output (0-1000) in % (0.0-100.0%)
FFFF = ffff
GG = Data status byte 0
HH = Data status byte 1
II = Data status byte 2
JJ = Data status byte 3
Bit GG HH II JJ
Bit0 (lsb) Fahrenheit active Controlling active Setup0 Display 0
Bit1 Status output 1 AutoTune active Setup1 Display 1
Bit2 Status output 2 AutoTune at controller start Setup2 Display 2
Bit3 Status output 3 Device ready Unused Unused
Bit4 Status input 1 Device hardware error Unused Unused
Bit5 Status input 2 Controller finished (successful) Unused Unused
Bit6 Status input 3 Targeting light active Unused Unused
Bit7 (msb) Status input 4 State input 5 Unused Unused
br
X
Baud rate serial interface
X=2...6,8..9,a,b 2 = 4800 Baud 5 = 38400 Baud 9 = 230400 Baud
3 = 9600 Baud 6 = 57600 Baud a = 460800 Baud
4 = 19200 Baud 8 = 115200 Baud b = 921600 Baud
eg1
XXXX
Emissivity
XXXX=0x0032...04b0 (corresponds 0050-1200 = 5-120%; in 0.1% steps)
et
XXXXXX
Response time (in steps of 100 µs)
XXXXXX=0x000000-0186A0 (corresponds 0-10 s)
fh
X
Celsius/Fahrenheit selection
X=0...1; 0 = Celsius; 1 = Fahrenheit
ff1
XXXX
Spot size filling
XXXX=0x0032...03e8 (corresponds 0050-1000 = 5%-100%) in 0.1% steps
fs
Read error status
Bit0 = DDC 114 error Bit 4 = error device temperature over
Bit 1 = I2C error (video module) Bit 5 = error Eeprom
Bit 2 = error device temperature Bit 6 = error motorized optics
Bit 3 = error detector temperature Bit 7 = unused
ga
XX
Device address
XX = 00...97 (2-digit dec.)
gh
(ghX)
XYYYY
Hysteresis for limit switch
X=1...3 to value YYYY (in 1/10 degree)
gk
(gkX)
XYYYY
Threshold for limit switch X
X=1...3 to value YYYY (in 1/10 degree)
