Technical specifications
for the LuMon System
79 of 93
Properties
Specifications
rotation angle of 0°, 90°, 180° or 270° (or 90°).
Inclination
Measurement Range 0-360°
To indicate inclination , the Inclination icon has 7 states, each spanning a specified
inclination angle range (6.6.1).
Table 13-4: Environmental conditions
Environmental
conditions
Properties
Part
Specifications
Temperature
Operation:
LuMon Monitor
10 °C to 35 °C
SensorBeltConnector
LuMon Connector
10 °C to 35 °C
10 °C to 38 °C
SensorBelts
LuMon Belts
10 °C to 35 °C
10 °C to 40 °C
ContactAgent/LuMon Contact
Spray/NeoContactAgent
10 °C to 40 °C
Transport:
LuMon Monitor
-20 °C to 60 °C
SensorBeltConnector
LuMon Connector
-20 °C to 70 °C
-20 °C to 65 °C
SensorBelts
LuMon Belts
-25 °C to 70 °C
-25 °C to 70 °C
ContactAgent/LuMon Contact Spray
NeoContactAgent
≤ 50 °C, keep away from sun light
≤ 60 °C
Upright Storage:
LuMon Monitor
-20 °C to 60 °C
SensorBeltConnector
LuMon Connector
5 °C to 40 °C
5 °C to 40 °C
SensorBelts
LuMon Belts
5 °C to 40 °C
5 °C to 40 °C
ContactAgent
LuMon Contact Spray
NeoContactAgent
0 °C to 25 °C keep away from sun light
0 °C to 30 °C keep away from sun light
0 °C to 30 °C
Atmospheric
pressure
Operation:
LuMon Monitor
660 to 1060 hPa (10.15 to 15.37 psi)
Transport:
LuMon Monitor
500 to 1060 hPa (7.25 to 15.37 psi)
Upright Storage:
LuMon Monitor
500 to 1060 hPa (7.25 to 15.37 psi)
Relative humidity
Operation:
LuMon Monitor
15 to 90% non-condensing
Transport:
LuMon Monitor
10 to 95% non-condensing
Upright Storage:
LuMon Monitor
10 to 95% non-condensing
Ingress protection
(IEC 60529)
LuMon Monitor
IP22
SensorBeltConnector
LuMon Connector
IP54 (MatchBox), IPX1 (ControlBox)
IPX1
Table 13-5: Intra-system compatibilities
System
Intra-system compatibilities
LuMon Monitors
Adult
supports SensorBeltConnectors and SensorBelts OR LuMon Connectors and LuMon Belts Adult
LuMon Monitors
Neo
only support LuMon Connectors and LuMon Belts Neo
