Sentec LuMon System - 1.2 About This Users Guide; 1.3 Symbols, Terminology and Abbreviations

Introduction
6 of 93
for the LuMon System
1.2
T rate and maintain the LuMon System. Before
attempting to operate the LuMon System, read this and pay special attention to the safety
information (2). Strictly observe all warnings and cautions.
LuMon System indications and contraindications are provided in section 3. The principle of operation and
limitations of EIT in general and Sentec EIT in particular are elucidated in 4. A brief description of the
components of the LuMon System is provided in 5. Section 6 describes the Graphical User Interface (GUI) of
the LuMon Monitor. How to install the LuMon System is explained in 7.
Section 8 explains how to apply the belts and to initiate monitoring, a description of the information displayed
while monitoring is provided in 9, and how to pause or end monitoring is outlined in 10.
Maintenance and troubleshooting related information are provided in 11 and 12, respectively. The technical
specifications for the LuMon System, finally, are provided in section 13.
NOTE
Statements in LuMon Monitors with the software versions indicated
on the cover page, an be any number. The software versions of the LuMon Monitor GUI and TIC
(0) - are displayed in the area of ScoutView (Figure 6-8). If your LuMon Monitor has other
so
Guide for the LuMon System (see www.Sentec.com/education/eit/plpm-eit).
1.3 Symbols, terminology and abbreviations
Safety symbols and messages are defined in sub-section 2.1.
A glossary of symbols used on the products of the LuMon System (1.1), on their packaging and in the
associated documentation is provided in sub-section 2.4.
A li -section 14.2.
• Table 14-1 defines generalized product terms for those products of the LuMon System that have
different variants. Unless the differentiation between the product variants is of importance for a
specific context, the generalized product terms will be used.
• Table 14-2 defines Sentec EIT related terms.
Notice that those terms being italicized and/or capitalized in Table 14-2 are italicized and/or Capitalized
throug
Also notice that the symbol ( ) identifies information and instructions being applicable only to the
Adults/Children configuration of the LuMon System whereas the symbol ( ) identifies information and
instructions being applicable to its Neonates/Infants configuration only.
d in 0.
