NOTE
A copy of the declaration of conformity can be requested from the manufacturer (Sentec AG, Kantonstrasse 14,
7302 Landquart, Switzerland).
13.8 EMC declaration
The LuMon System is intended for use in the electromagnetic environment specified below.
Table 13-16 Electromagnetic emissions - ation
Electromagnetic environment guidance
The LuMon System uses RF energy only for its internal functions.
Therefore, its RF emissions are very low and are not likely to cause any
interference with nearby electronic equipment.
The LuMon System is suitable for use in all establishments other than
domestic and those directly connected to the public low-voltage power
supply network that supplies buildings used for domestic purposes.
Table 13-17 Electromagnetics immunity - Guidance and manu eclaration
Electromagnetic environment guidance
Electrostatic discharge
(ESD)
IEC 61000-4-2
± 8 kV contact
± 2 kV, ± 4 kV, ± 8 kV, ± 15
kV air
± 8 kV contact
± 2 kV, ± 4 kV, ± 8 kV, ±
15 kV air
Floors should be wooden, concrete or ceramic tile. If
floors are covered with synthetic material, the relative
humidity should be at least 30%.
Electrostatic discharge may cause measurement
artefacts, or the measurement may be temporarily
interrupted.
Electrical fast
transient/burst
IEC 61000-4-4
± 2 kV for power supply
lines
± 1 kV for input/output
lines
± 2 kV for power
supply lines
± 1 kV for input/output
lines
Mains power quality should be that of a typical
commercial or hospital environment.
Electrical fast transients may cause measurement
artefacts, or the measurement may be temporarily
interrupted.
± 0.5 kV, ± 1 kV line(s) to
line(s), ± 0.5 kV, ± 1 kV, ±
2 kV line(s) to earth
± 0.5 kV, ± 1 kV line(s)
to line(s), ± 0.5 kV, ± 1
kV, ± 2 kV line(s) to
earth
Mains power quality should be that of a typical
commercial or hospital environment.
Voltage dips, short
interruptions and
voltage variations on
power supply
input lines
IEC 61000-4-11
<5% U
T
(0,5 cycle)
40% U
T
(5 cycles)
70% U
T
(25 cycles)
<5% U
T
for 5 s
<5% UT (0,5 cycle)
40% U
T
(5 cycles)
70% U
T
(25 cycles)
<5% U
T
for 5 s
Mains power quality should be that of a typical
commercial or hospital environment. If the user of the
LuMon System requires continued operation
during power mains interruptions, it is recommended
to provide the LuMon Monitor with power from an
uninterruptible power supply or a battery.
Note: U
T
is the a.c. mains voltage prior to application of the test level.
Power frequency
(50/60 Hz) magnetic
field
IEC 61000-4-8
Power frequency magnetic fields should be at levels
characteristic of a typical location in a typical
commercial or hospital environment.
Portable and mobile RF communications equipment should be used no closer to any part of the LuMon System, including cables,
than the recommended separation distance d calculated from the equation applicable to the frequency of the transmitter.
Conducted RF
IEC 61000-4-6
3 Vrms
150 kHz to 80 MHz
6 Vrms
c)
in ISM bands
between 0,15 MHz and
80 MHz
3 Vrms
150 kHz to 80 MHz
6 Vrms
c)
in ISM bands
between 0,15 MHz
and 80 MHz
Conducted RF disturbances may cause
measurement artefacts, or the measurement may be
temporarily interrupted.
Radiated RF
IEC 61000-4-3
3 V/m
80 MHz to 6 GHz
9-28 V/m
385 MHz-5.785 GHz
d)
3 V/m
80 MHz - 6 GHz
9-28 V/m
385 MHz-5.785 GHz
d)
d = 1.17 *SQRT(P) 80 MHz ot 800 MHz
d =2.33 *SQRT(P) 800 MHz ot 6 GHz
Radiated RF disturbances may cause measurement
artefacts, or the measurement may be temporarily
interrupted.
Field strengths from fixed RF transmitters, as determined by an electromagnetic site survey
a
, should be less than the compliance level in
each frequency range. Interference may occur in the vicinity of equipment marked with the following symbol
b
:
Note: At 80 MHz and 800 MHz, the higher frequency range applies.
Note: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from
structures, objects and people.
