Sepura SC20 series User Manual

Note: Your radio must be powered on and have sufficient battery charge
for the duration of the customisation process.
To program a single radio
A data/programming cable, with either an RS232 (D-type) connector or a USB
connector, is available from Sepura for customising a single radio.
1. Connect the USBprogramming cable to the computer.
2.
Connect the cable to the radio by inserting the hook on the connector into
the slot as shown.
3.
Secure the cable in position. Do not over tighten.
4. When programming is complete disconnect the cable from the radio.
User Guide
139

Sepura SC20 series Specifications

General

Operating Temperature	-30°C to +60°C
Frequency Bands	380-430 MHz
GPS	Integrated GPS, GLONASS
Bluetooth	Bluetooth 4.0
Security	TEA1, TEA2, TEA3
Transmit Power	1W, 3W, 10W
Battery Life	Up to 14 hours (standard battery)
