Sepura SC21 Series User Manual

Shirt/Pocket clip
The shirt/pocket clip (part no. 300-01922) is used to attach your radio to clothing, such as a shirt or
trouser pocket. The clip is fitted to the mounting clip attachment points on the back of the radio.
You do not have to remove the clip before charging the battery. The radio can be inserted into any of
the SC21 battery chargers with the battery and belt clip attached.
Attaching the shirt/pocket clip
Caution! Risk of damage to the radio. Ensure the shirt/pocket clip screws are secure, but
do not over tighten. If using a torque screwdriver, apply a maximum torque of 45 Ncm or
equivalent.
1.
Using a PZ1 screwdriver attach the shirt/pocket clip to the two attachment points as shown.
MAX 45 Ncm
PZ1 x 2
Do not over tighten
Removing the shirt/pocket clip
1. Using a PZ1 screwdriver remove the shirt/pocket clip from the two attachment points.
PZ1 x 2
122 SC21 Series hand-portable radio

Sepura SC21 Series Specifications

General

IP Rating	IP54
Operating Temperature	-20°C to +55°C
Channel Spacing	25 kHz
Ingress Protection	IP54
Channels	Up to 2000
Frequency Bands	380-430 MHz, 806-870 MHz
Battery Life	Up to 14 hours
RF Power Output	1W
TETRA Air Interface	ETSI EN 300 392-2
