R301 RF POWER SUPPLY OPERATOR’S MANUAL
command. A negative (-) polarity signal is assumed.
Command: 0?
Response: -XXXX
DR Select VOLTAGE CONTROL mode
Selects the Analog Interface connector’s FEEDBACK signal as the
feedback source for regulating the RF output level. Related commands:
“V?”, “0?”, and “V”.
Command: DR<cr>
Response: <prompt><cr>
IR Select POWER CONTROL mode
Selects the R301’s internal power sensor as the feedback source for
regulating the RF output level. Used in conjunction with the “DL”, “EL”,
and “W” commands.
Command: IR
Response: <prompt><cr>
DL Select FORWARD POWER leveling
Configures the R301 to deliver a constant Forward Power the load. The
power setpoint is set by the front panel controls or the “W” serial
command.
Command: DL<cr>
Response: <prompt><cr>
EL Select LOAD POWER leveling
Configures the R301 to deliver a constant Net Power to the load. Net
Power = (Forward Power – Reflected Power). The power setpoint is set
by the front panel controls or the “W” serial command.
Command: EL<cr>
Response: <prompt><cr>
+P Enable the PULSE mode
Enables pulsing of the RF output, per the parameters specified in the
programming menu or by the serial commands “D”, “HT”, “LP”, and
“HP”
Command: +P<cr>
Response: <prompt><cr>
-P Disable the PULSE mode
Disables pulsing of the RF output
Command: -P<cr>
Response: <prompt><cr>
G Enable the RF Output
Command: G<cr>
Page 21
Seren IPS Inc.
6100130000 Rev. 0.05
