R301 RF POWER SUPPLY OPERATOR’S MANUAL
To Send Description/Comment
Response: <prompt><cr>
Set the Process Pulse Low
Power Setpoint
XXXX_LP<cr> XXXX is the process pulse low power
setpoint, in Watts. 1 to 4 digits.
Response: <prompt><cr>
Set the Process Pulse High
Power Setpoint
XXXX_HP<cr> XXXX is the process pulse high power
setpoint, in Watts. 1 to 4 digits.
Response: <prompt><cr>
Enable ECHO mode ECHO<cr> Response to commands includes the
<prompt> plus the command string sent
to the unit, terminated with <cr>.
Response: <prompt><cr>
Disable ECHO mode NOECHO<cr> Suppresses the echo of commands.
Response for accepted (acknowledged)
commands is <prompt><cr>.
Response for invalid commands is
N<cr>
Response: <prompt><cr>
