R301 RF POWER SUPPLY OPERATOR’S MANUAL
Level Parameter Detail
Factory default setting is 50%
15 Tune Capacitor Preset Position:
Sets the Tune Capacitor preset position voltage output for an external matching network.
Adjustable from 0% (0.0VDC output) to 100% (+5.0VDC), in 1% (50mV) increments.
With Matching Network Preset Mode enabled and the RF output disabled, the Tune Capacitor
preset position voltage (0 to +5.0VDC) is present at the analog interface connector’s FWD MON
(forward power monitor) signal (pin 10).
Note:
this feature designed for use with the Seren IPS Inc. MC2 matching network controller and
AT-Series automatic matching networks.
Related menu item: 13
Factory default setting is 50%
Page 33
Seren IPS Inc.
6100130000 Rev. 0.05
