R301 RF POWER SUPPLY OPERATOR’S MANUAL
Level Parameter Detail
12 DC Voltage Control Gain
Factory default setting is 100%
Matching Network Preset Mode:
Enables or disables the Matching Network Preset feature and configures the behavior of the
analog interface connector RFENABLED* signal (pin 8) when the Matching Network Preset
feature is enabled.
ENABLE MATCH PRE INV When the RF output is disabled, the matching network
preset position voltages are present on the analog
interface connector’s FWD MON and REFP MON
signal pins.
Analog interface connector RFENABLED* signal
(pin 8) outputs a TTL logic high (1) state when the RF
output is enabled and the reflected power threshold
alarm has not been exceeded.
Analog interface connector RFENABLED* signal
(pin 8) outputs a TTL logic low (0) state when the RF
output is disabled or when the reflected power
threshold alarm has been exceeded.
ENABLE MATCH PRESET When the RF output is disabled, the matching network
preset position voltages are present on the analog
interface connector’s FWD MON and REFP MON
signal pins.
Analog interface connector RFENABLED* signal
(pin 8) outputs a TTL logic low (0) state when the RF
output is enabled and the reflected power threshold
alarm has not been exceeded.
Analog interface connector RFENABLED* signal
(pin 8) outputs a TTL logic high (1) state when the RF
output is disabled or when the reflected power
threshold alarm has been exceeded.
DISABLE MATCH PRESET Disables Matching Network Preset feature (Factory
default setting)
13
Note:
This feature is designed for use with the Seren IPS Inc. MC2 matching network controller
and AT-Series automatic matching networks. The MC2 controller, AT-Series matching
networks, and interface cabling are not supplied with the R301 product and must be purchased
separately.
Related menu items: 14, 15
14 Load Capacitor Preset Position:
Sets the Load Capacitor preset position voltage output for an external matching network.
Adjustable from 0% (0.0VDC output) to 100% (+5.0VDC), in 1% (50mV) increments.
With Matching Network Preset Mode enabled and the RF output disabled, the Load Capacitor
preset position voltage (0 to +5.0VDC) is present at the analog interface connector’s REFP MON
(reflected power monitor) signal (pin 11).
Note:
this feature designed for use with the Seren IPS Inc. MC2 matching network controller and
AT-Series automatic matching networks.
Related menu item: 13
Page 32
Seren IPS Inc.
6100130000 Rev. 0.05
