SCORPIO 38’ - 45’ - SECURITIES & RECOMMENDATIONS - Potential dangers for the user
Version 1.02 May 27, 2022
SERVICEVISION BIS SL
Ríos Rosas, 20 · 08940 CORNELLA DE LLOBREGAT (Barcelona) Spain · Tel. 34 93 223 86 30 · Fax 34 93 223 86 31 63
comercial@servicevision.es · www.servicevision.es
Event on the crane
Risk associated
Working with the crane
unbalanced
There is a risk of not being able to control the movement of the
crane. Balance the crane before operating it.
One broken/damaged steel
side cable
If one of all the side cables brakes, there is no risk or danger. The
cables must be replaced for the optimum arm behavior.
All the cables from one
section break
There will be no control of the section and the sections behind it, it
will be detached from the system and therefore uncontrollable. The
crane cannot work until the cables have been replaced.
The main section cables
moving the first section
break
In this case the telescopic arm will not move. Replace the cable to
use the crane again.
One broken/damaged steel
CWE cable
If one cable is broken there is no risk or danger. The cable must
be replaced for the optimum arm behavior.
All the cables from the
CWE break
If the crane is in the horizontal position no risk will happen. If the
crane is tilted, even slightly, the CWE trolley will move freely and
the balance of the crane will be lost. The crane cannot work until
the cables have been replaced.
Moving the telescopic arm
with something blocking it
There is a risk to burn the motor or damage some mechanical
component. Remove anything blocking the telescopic section
before operating the crane.
One guiding wheel breaks
or is too tight
The rail can be damage and the movement of the crane is not
smooth. Replace/readjust the wheel.
Upper bars or rear side
bars broken/damaged
If one or several bars brake, there are no specific risks or danger.
It must be replaced for the optimum arm behavior.
The dynamic CWE belt
breaks
It might be possible that the counterweights move freely along the
range. Replace the belt or it could happen sudden changes on the
balance of the crane while operation.
The main motor/gearbox is
broken
There are no risks associated to this event but the crane cannot
work, it will be blocked in the position it has when the event occurs.
Pan or Tilt brake loose
The crane will be moved freely by the wind and it can hit anything
in the surroundings.
Electronic box breaks
The crane will stop but there are no risks associated. Replace the
electronic Box to operate the crane again.
Leveling Head breaks
There will be no correction of the horizon.
Working in Electrical storm
conditions (lighting and
thunderstorms)
There is the risk of serious injury and death by electrocution or
burns for the operators/technicians or any personnel near the
crane.
Wind Speed
The consequences of ignoring the maximum wind speeds
permitted to operate each Scorpio crane will lead into
overturning/capsize. With a REAL RISK of injuring crew and
personnel around the camera car.
5.3 POTENTIAL DANGERS FOR THE USER
There are mechanical dangers to behold, but if the crane is manipulated with all protections,
equipment covers and instructions received under both the user’s manual and the training given
by Servicevision’s authorized trainee, it should be no danger.
