LEAK FINDING TEST
COMPANY NAME: __________________________TEL:____________________
CONTACT PERSON:_________________________FAX:____________________
ANALYZER’S SERIAL NUMBER: _____________E-MAIL:_________________
APPROXIMATE TIME ELAPSED SINCE START-UP: _____________________
ZONE 1 TEST
WE SUGGEST TO USE THE ZERO CALIBRATION GAS TO RUN THE TEST
PPM VALUE OF THE GAS BEING USED: _____ ppm
PRESSURE READ
ON REGULATOR
FLOW DISPLAYED
BY ANALYZER
PPM DISPLAYED CELL COUNTS
NORMAL
PRESSURE
LOW
PRESSURE
ZONE 2 TEST
WE AGAIN SUGGEST TO RUN THIS TEST WITH THE ZERO CALIBRATION GAS
PPM VALUE OF THE GAS BEING USED: _____ ppm
PRESSURE READ
ON REGULATOR
FLOW DISPLAYED
BY ANALYZER
PPM DISPLAYED CELL COUNTS
75 CC FLOW
25 CC FLOW
OVERALL PERFORMANCE VERIFICATION
PPM VALUE CELL COUNTS
ZERO CALIBRATION GAS:
SPAN CALIBRATION GAS:
It is also a good idea to verify for possible changes in analyzer reading using the span gas and do again
the tests for zone 1 and zone 2. So you can optionally fill in the two following tables.
