Digital Weighing Indicator
SI 4100
- 24 -
■ Relay Output Mode Setting
Weighing Mode selection
F21
●
1
Limit Mode 1. (Relay “ON”, when current weight reaches set value)
2
Packer Mode
3
Check weighing Mode 1.
4
Check weighing Mode 2.
5
Limit Mode 2. (Relay “OFF”, when current weight reaches set value)
6
User’s Choice Relay Output Mode 1. (“B” Dry Contact relay)
- User can arrange “Sp1~4” relay output sequence, by setting
7
User’s Choice Relay Output Mode 2. (“A” Dry Contact relay)
- User can arrange “Sp1~4” relay output sequence, by setting
8
Accumulating Mode1
9
Packer Mode 2 (User’s Choice relay)
10
Accumulating Mode2
Relay output Mode(Each weighing Mode)
Weighing Mode
Output1
Output2
Output3
Output4
Output5
Output6
1
Limit Mode 1.
Sp1“ON”
Sp2“ON”
Sp3“ON”
Sp4“ON”
FINISH
Near Zero
2
Packer Mode
Sp1
Sp2
Sp3
Sp4
FINISH
Near Zero
3
Check weighing Mode 1.
Near Zero
Sp1
Sp2
Sp3
Sp4
Near Zero
4
Check weighing Mode 2.
Near Zero
Sp1
Sp2
Sp3
Sp4
Near Zero
5
Limit Mode 2.
Sp1“OFF”
Sp2“OFF”
Sp3“OFF”
Sp4“OFF”
FINISH
Near Zero
6
User’s Choice 1
Sp1“OFF”
Sp2“OFF”
Sp3“OFF”
Sp4“OFF”
FINISH
Near Zero
7
User’s Choice 2
Sp1“ON”
Sp2“ON”
Sp3“ON”
Sp4“ON”
FINISH
Near Zero
8
Accumulating Mode1
SP1
“ON”
SP1+SP2
“ON”
SP1+SP2
+SP3 “ON
SP1+SP2+SP3
+SP4 “ON“
FINISH
Near Zero
9
Packer Mode-User’s
Choice
SP1
SP2
SP3
SP4
FINISH
Near Zero
10
Accumulating Mode2
SP1
“ON”
SP1+SP2
“ON”
SP1+SP2
+SP3 “ON
SP1+SP2+SP3
+SP4 “ON“
FINISH
Near Zero
