Sewhacnm SI 4100 - Write Commands in Command Mode

Digital Weighing Indicator
SI 4100
- 55 -
STX ID NO. RSP4 ETX
SP4 Set value
SP4 Set value Data Transfer
-STX IN NO. RSP4 Set value(7/8byte) ETX
STX ID NO. RPNO ETX
P/N data
P/N Set value Data Transfer
-STX IN NO. RPNO P/N Set value(2byte) ETX
STX ID NO. RWRS ETX
Current Indicator
situation
(weight, relay output)
Current indicator value transmit(including decimal point 7/8byte)-
STX ID NO. RWRS current
+/- (1byte) current weight(7/8byte),input situation(4byte),relay
output(6byte).ETX
6-9-2. Write Command
P.C ->> SI 4100
Command
SI 4100 Response
STX ID NO. WZER ETX
To make Current Weight as Zero
ACK or NAK
STX ID NO. WTAR ETX
TARE
ACK or NAK
STX ID NO. WTRS ETX
TARE Reset
ACK or NAK
STX ID NO. WPRT ETX
Print
ACK or NAK
STX ID NO. WSPR ETX
SUB-Total Print
ACK or NAK
STX ID NO. WGPR ETX
GRAND Total Print
ACK or NAK
STX ID NO. WSTC ETX
Delete SUB-Total Data
ACK or NAK
STX ID NO. WGTC ETX
Delete GRAND-Total Data
ACK or NAK
STX ID NO. WSTR ETX
RUN
ACK or NAK
STX ID NO. WSTP ETX
STOP
ACK or NAK
STX ID NO. WTIM Time Data(6byte) ETX
TIME Setting
ACK or NAK
STX ID NO. WDAT Date Data(6byte) ETX
DATE Setting
ACK or NAK
STX ID NO. WSP1 SP1 data(7/8byte) ETX
SP1 Setting
ACK or NAK
STX ID NO. WSP2 SP2 data(7/8byte) ETX
SP 2 Setting
ACK or NAK
STX ID NO. WSP3 SP3 data(7/8byte) ETX
SP 3 Setting
ACK or NAK
STX ID NO. WSP4 SP4 data(7/8byte) ETX
SP 4 Setting
ACK or NAK
STX ID NO. WPNO Part No. Data(2byte) ETX
P/N Change
ACK or NAK
 How to Calculate Check sum.
Sum the value from “STX” to “ETX” and converts to ASCII(2byte) and transfer.
Convert the Sum value(HEX) to ASCII and transmit(28byte) .
ex) The sum HEX value from STX to ETX(02,30,31,52,43,57,54,03) is 1A6h.
Then, divide 1A6h by 100h(1A6h/100h). the rest of result is A6h.
Calculated remainder value is A6h, then convert A6h to ASCII, 41(A), 36(6), and transfer.
