FLIGHT MANUAL
SHARK 600
Section 8
Handling, Servicing
and Maintenance
2024-02-23
Rev. A
Doc. No.: SHARK600_MA_075
Reinforced surfaces:
Fuselage-fin connection. Circle with radius 350 mm, where
fuselage can be pushed down to lift the front wheel
Leading edge of fin up to 500 mm height, 100 mm wide on each
side
Top part of the wing leading edge, 200 mm wide area
Top part of the stabilizer leading edge, 150 mm wide area
Area around fuel caps
Stepping surface on left wing root - fuselage part
Whole upper surface of the wing is reinforced, but maximum
load is still limited
Spinner
Root part of propeller blades can be used for towing, don’t
push or pull on the tip!
CAUTION
The Shark 600 composite surface is created by thin layer of carbon fabric,
to keep the lowest possible weight. Under the carbon fibre layer is a
layer of PVC foam with relatively low firmness and stiffness. Common
hand pressure can result in surface damage and complicated repair.
Gentle ground handling is therefore highly recommended.
