18
ALIGNING THE PRINT HEADS
7
Specify the best values for "C Pattern", "D Pattern" settings in
the same manner. (select from -6 to +6)
8
A message asking you to confirm your settings will appear. If
you have entered the desired settings, keep pressing the (or
) "ARROW" button until "2. Yes" appears on the second line
of the display panel. Press the "ENTER" button to activate the
new print head setting.
After "1.No" appears on the second line of the display panel and you press the
"ENTER" button, the message appearing in step 5 will appear in the display panel.
9
Print a test page to check print quality.
For details refer to "PRINTING A TEST PAGE". (See page 55)
10
Make sure that the following parameters appear on the display
panel.
Example
Look at the chart C and D on your test chart. Select the
numbers under the pattern samples, which have the straightest
lines.
Select C pattern
+1 - +
-6 -5 -4 -3 -2 -1 0 +1 +2 +3 +4 +5 +6
-6 +1
In the example shown above, "+1" shows the straightest line.
Therefore, select "+1" to show on the display panel, and then
press the ENTER button.
Are you sure?
2.Yes
Ready to Copy
100% A4 0
To Next Page
