AL-2041 SIMULATION, TROUBLE CODES 10 - 10
30 01 Paper sensor status display [Function]
The paper sensor status is displayed on the LED.
∗ Since the manual paper feed sensor is a single bypass sensor, its status is not displayed.
41 06 OC cover float detection
level adjustment
(excluding AL-2021)
[Function]
When this simulation is executed, the current set value is displayed. When [START] key is
pressed, the mirror base unit moves to the SPF scan position to acquire the OC cover float
detection level.
When the mirror base unit returns to the home position, the acquired value is displayed.
If the adjustment is NG, the following message is displayed.
AL-2031/2041: Misfeed lamp lights up, and the 7seg display remains unchanged.
Note that, this simulation must be executed with the OC cover closed.
∗ If the value is 0, float detection is not performed in normal jobs.
07 OC cover float detection
margin setting
(excluding AL-2021)
[Function]
For the number of pixels between black markers on the SPF scanning position saved in "41-06:
(OC cover float detection level adjustment)", if the number of pixels between the markers when
processing float detection is less than the number of pixels set with this simulation, it is judged
as the float error.
When the set value of this simulation is "0," no float error occurs.
When this simulation is executed, the current set value is displayed.
Enter the adjustment value with [ ] [ ] key and press [START] key. The setting is saved and
the display is shifted to the sub code input standby menu.
Setting range: 0 – 99 (Copes with margin 0 – 99 pixels.)
Default: 30 (30 pixels)
[Operation]
The operation is similar to simulation 9-04.
43 01 Fusing temperature setting
(Normal copy)
[Function]
Used to set the fusing temperature of 3rd or later sheet. (For 1st and 2nd sheets, SIM 43-14 is
used.)
When this simulation is executed, the current set code number is displayed. Press [ ] [ ] key
to change the setting and press [START] key to save the setting into the EERPOM.
The machine goes into the sub code entry standby mode.
The [Exposure mode selector] key is used to select the mode.
[Operation]
1) Press [Exposure mode selector] key to change the mode.
2) Press [ ] [ ] key to set the value.
3) Press [START] key to fix the code number.
Main
code
Sub
code
Contents Details of function/operation
Sensor Signal Display lamp
Paper exit sensor POD Photoconductor cartridge
replacement lamp
Paper entry sensor PPD1 Developer cartridge replacement
lamp
Duplex sensor PPD2 JAM lamp
New drum cartridge
sensor
PUIS Zoom lamp
* The cassette feed and the manual feed are controlled similarly.
Code
Set temperature
(°C)
Remark Code
Set temperature
(°C)
Remark
0 170 5 195 Default
1 175 6 200
2 180 7 205
3 185 8 210
4 190
Mode Display item
Main cassette paper
feed
AE mode lamp
Manual paper feed TEXT mode lamp
