AL-2040CS SIMULATION, TROUBLE CODES 10 - 12
46 30 AE limit adjustment
AE and the limit value of AE (toner save) are set.
Setting is changed. When START key is pressed, the set content is written into the EEPROM and the display returns to the
sub code input standby mode.
When UP key is pressed, the setting is changed over. (Set range: 0 – 31, Default: 0)
Each mode can be selected by pressing the density select key.
For UP keys, only 1UP key is valid. (10UP key is invalid.)
<Remark>
When SIM 26-06 is changed or SIM 46-19 automatic exposure mode is changed, this setting is also changed to the default
value.
31 Image sharpness adjustment
Used to adjust the clear/shading-off of an image in each mode.
(Operating procedure)
When this simulation is executed, warm-up and shading operations are performed and the current setup value is displayed.
(Default: 1)
Change the setup value with the copy quantity keys. Press the PRINT switch and a copy is made according to the new setup.
When the clear key is pressed, the entered setup value is saved and the simulation is terminated.
Any desired copy mode can be selected with the copy mode select key. The code number of the selected copy mode is
displayed on the copy quantity display.
32 Copier color reproduction setup
Used to set color reproduction for each mode. Colors which are easily copied or which are not easily copied are selected.
(Operating procedure)
When this simulation is executed, the current setup of the code number for each copy mode is displayed. (Default: 0)
Change the setup value with the copy quantity keys and press the Print switch. A copy will be made according to the setup. At
that time, the color component used for copying is changed.
When the clear key is pressed, the entered code number is saved and the simulation mode is terminated.
Any desired copy mode can be selected with the copy mode select key. The selected copy mode is displayed on the copy
quantity display.
Main
code
Sub
code
Content
Mode Display lamp
AE limit value AE mode lamp
AE (toner save) limit value TEXT mode lamp
Setup value Image quality
0 Shading off
1 Standard * Default
2 Clear
Copy mode Display lamp
AE mode AE mode lamp
TEXT mode TEXT mode lamp
PHOTO mode PHOTO mode lamp
TS mode (TEXT) TEXT mode lamp & PHOTO mode lamp
TS mode (AE) AE mode lamp & PHOTO mode lamp
∗ This setup does not affect black-and-white copies.
Setup value Easy-to-copy colors Difficult-to-copy colors
0 Purple/Blue/Red Yellow/Green/Light blue
1 Light blue/Green/Blue Purple/Red/Yellow
2 Yellow/Red/Green Blue/Light blue/Purple
Code number Component of use
0 Green * Default
1Red
2Blue
Copy mode Display lamp
AE mode (including TS) AE mode lamp
TEXT mode (including TS) TEXT mode lamp
PHOTO mode PHOTO mode lamp
