AL-2040CS SIMULATION, TROUBLE CODES 10 - 13
48 01 Front/rear (main scanning) direction and scan (sub scanning) direction magnification ratio adjustment
The magnification ratios in the main scanning direction (front/rear) and in the sub scanning direction are adjusted.
Enter the adjustment value with 10-key, and press START key to save the entered value, and make a copy. (When the set
value is increased by 1, the magnification ratio is increased by 0.1%.)
The adjustment mode can be selected with the density select key. (Adjustment range: 1 – 99, Default: 50)
05 The current SPF mode sub scan direction magnification ratio is displayed on the LCD/7seg.
When START key is pressed, the entered data are obtained and saved into the EEPROM, and a copy is made. (When the set
value is changed by 1, the ratio is increased by 0.1%.) (Set range: 1 – 99, Default: 50)
Each mode can be selected by pressing the density select key.
∗ When there is no document in the SPF, copy is inhibited.
49 01 Flash ROM program writing mode
(Operating procedure)
When this simulation is executed, “d” is displayed on the display and the machine enters the Flash ROM program writing
mode.
Use the writing tool to write the program from PC. During writing, the display indicates as shown below. After completion of
downloading, turn OFF/ON the power to reset.
Main
code
Sub
code
Content
Mode Display lamp Default
Main scanning direction magnification ratio TEXT mode lamp 50
OC mode sub scanning direction magnification ratio PHOTO mode lamp 50
Mode Display lamp Lamp ON Default
Sub scanning direction magnification ratio
adjustment on the SPF document front surface.
COPY mode lamp AE mode lamp 50
∗ “*” in an error display indicates the error position.
Status Display Pre-heat lamp Ready lamp
Download data reception “d” ON ON OFF
Data erase start “d” ON OFF ON
Data writing (Boot section) “d” ON Blink OFF
Data writing (program section) “d” ON Blink Blink
Sum check “d” ON ON ON
Download complete “0FF” ON OFF OFF
Error state “E *” ON OFF OFF
1 Data reception error
2 Loader function transfer
3 FLASH ROM delete
4 FLASH ROM writing (Boot section)
5 FLASH ROM writing (Program section)
6 Sum check (Loader section)
7 Sum check (Boot section)
8 Sum check (Program section)
