E-22
Installing the wall-mount bracket (For Model 30 inch Separate Type) (Continued)
Attachment bracket
(Top side)
(Bottom side)
Attachment bracket
Install the attachment bracket.
Use the 6 screws removed in Step 2 (Page 21) to attach the attachment bracket.
Perform the cable work.
3
4
• When installing the wall-mount bracket, use the attachment that matches the model of LCD
color TV that was purchased.
Caution
Attachment HV (41 mm thick) LC-30HV2/4, LC-30HV6, LC-30AA1, LC-30AD1*(2)
*(2) Models for which the destination market is other than Japan.
