Coin Vend Interface
18
Document Solutions After Sales Service
All MX series machines have a coin vend interface located on the PCU Main PWB. The vending device activates
various signals to indicate paper sizes and operation.
Because of additional functionality, the interface connector has been changed from 12 to 16 pins.
Connector Manufacture: CABCOM
Connector Type Interface Cable
Connector Part Code (Wire Side) L80INVENDKIT5
Before connecting a third party auditor, the device should confirm to the following:-
1. The auditor interface should be optically isolated from the copier.
2. The device should be Power Supply Unit independent.
3. The device power supply unit should be a plug top adapter, not internal.
4. The plug top adapter should have a reinforced insulation barrier.
5. The audit device MUST hold a CE Mark.
To enable coin vend function, test simulation 26 –03 should be set as required:-
Diagnostic
Setting
The specified quantity
is completed.
Remainder of money
is left
Insufficient money during copy job
The specified
quantity is
completed.
No money
remaining
Black/Colour
(No money
remaining)
Colour
(Remainder of money
left)
Condition 1 Condition 2 Condition 3 Condition 4
MODE 1 Operation 1 Operation 2 Operation 2 Operation 1
MODE 2 Operation 1 Operation 1 Operation 2 Operation 1
MODE 3 Operation 1 Operation 3 Operation 2 Operation 3
OPERATION 1 Wait for auto clear setting time
(Default 60sec – can be changed by the system setting)
OPERATION 2 Auto clear is not made.
OPERATION 3 Setting is immediately cleared.
Cont.
