Sharp Gemini II Plus MX-2614N User Manual

Coin Vend Interface
19
Document Solutions After Sales Service
Connector Signals:
Pin No. PCU PWB (CN17)
1 + 24v Out
2 GND Out
3 CV_B/W_COPY In
4 CV_COUNT Out
5 CV_START Out
6 CV_CA Out
7 CV_COLOUR_ COPY In
8
CV_COLOUR1
Out
9
CV_STAPLE
Out
10 CV_COLOUR0 Out
11 CV_DUPLEX Out
12 5v Out
13 CV_SIZE0 Out
14 CV_SIZE1 Out
15 CV_SIZE2 Out
16 CV_SIZE3 Out
Colour Signal:
Colour Mode
Colour Mode 1
(CL-COLOR0)
Colour Mode 2
(CL-COLOR1)
B/W 0 0
Full Colour 1 1
Others
(Single/Two Colour)
0 1
Paper Size Signals:
SIZE3 SIZE2 SIZE1 SIZE0 PAPER SIZE
0 0 0 0 NIL
0 0 1 0 A4
0 0 0 1 A3
1 0 1 1 A3W
0 0 1 1 LT
0
1
0
0
B4
0
1
0
1
LG
0 1 1 0 WLT
0 1 1 1 INV
1 0 0 0 B5
1 0 1 0 A5
1 0 0 1 EXTRA
