Sharp Gemini II Plus MX-2614N

Simulation Codes
28
Document Solutions After Sales Service
The following pages contain information regarding test simulations. For a detailed description for each test
simulation, please refer to the MX2310U Service Manual.
Copier Simulation Entry Codes
On the copier operation panel, press the following keys:-
1
Scanner Self Test
1 Scanner operations test
2
Scanner sensor check
5
Scanner unit and control circuit check
2
RSPF Self Test
1 SPF ageing test.
2
SPF sensor check
3 SPF output check (motor, clutch, solenoid)
3
Finisher Operation / Test
2
Finisher sensor check.
3 Finisher output check (motor, clutch, solenoid)
10 Finisher adjustment
4
Desk/ LCC Operation / Test
2
Desk sensor check
3 Desk output check
5 Desk clutch operation check
5
Lamp Operation / Test
1 LCD/LED test
2 Heater lamp load check
3 Copy lamp check
4 Discharge lamp check
6
System Load Operation / Test
1 Feed output check
2
Fan load check
3 Transfer operation check
6 Fusing separation check
90 Set Mirror to Lock Position
7
Device Aging Operation / Test
1 Ageing test setting
6 Interval ageing cycle timer set up
8 Warm up time display setting
9 Printing colour select mode (colour)
12
Document reading setting (ageing)
8
High Voltage Operation / Test
1 Developer bias setting and output
2 MHV/Grid setting and output
6 Transfer setting and output
9
Duplex Operation / Test
2 ADU sensor check
3
ADU load & output check
10
Toner Motor Operation / Test
1 Toner motor operation check
13
Clear / Cancel
--
Trouble cancel (U1 trouble)
14
Clear / Cancel
--
Trouble cancel (H3, H4, H5 trouble)
15
LCC Clear / Cancel
--
LCC Trouble cancel (U6 trouble)
16
Clear / Cancel
--
U2 trouble cancel
17
Clear / Cancel
--
PF trouble cancel
21
Maintenance Cycle Configuration
1
Maintenance cycle setting
22
Data Output / Check
1 Counter data display
2 Jam/trouble counter display
3 Jam history data display
4
Trouble code history data display
5 ROM version display
6
Data print mode
8 Document feed and output counter display
9 Paper feed counter display
