MX-3610N MX-RB10/FN10 (PAPER PASS UNIT/FINISHER) 24 – 1
MX-3610N
Service Manual
[24] MX-RB10/FN10 (PAPER PASS UNIT/FINISHER)
1. Unpacking
A. Saddle finisher removal
For removal of the saddle stitch finisher, manpower of two persons
or more is required.
1) Holding the upper part of the saddle stitch finisher by two peo-
ple, pull up the saddle stitch finisher, and make it stand upright.
(Be careful to sliding worker's foot.)
2) Remove the skid and packing cushions.
3) One person tilt the saddle stitch finisher, another person
remove the lower tray.
4) Remove the other side similarly.
1
2
1
2

Sharp MX-2010U Specifications

General

Print Technology	Laser
Print Speed	20 ppm
Print Resolution	600 x 600 dpi
Scan Type	Color Scanner
Functions	Print, Copy, Scan, Fax
Copy Speed	20 cpm
Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Fax Transmission Speed	33.6 kbps
Duplex Printing	Yes
Maximum Paper Size	A3
Connectivity	USB, Ethernet
Hard Drive	80 GB
Weight	73 kg
