MX-3610N MX-AM10 (WEB BROWSING EXPANSION KIT) 32 – 1
MX-3610N
Service Manual
[32] MX-AM10 (WEB BROWSING EXPANSION KIT)
1. Unpacking
A. Packed items check
2. Installation
A. Enable setting of functions
1) Enter the product key to enable the functions.
a) Enter the system setting mode.
b) The machine enters the product key input mode.
c) Enter the product key.
d) Press the registration key.
2) After completion of the product key input, turn OFF the power
switch on the operation panel of the machine, and turn OFF
the main power switch.
3) Turn ON the main power switch and the power switch on the
operation panel.
4) Register the key.
a) Touch [Action panel] button on the right upper side of the
operation panel of the home screen, and select "Edit
home."
b) Select "Key registration."
c) Select the key to be registered.
With the above operations, the key icon appears on the home
screen.
B. Confirmation of function enable
Execute SIM22-10 (Machine configuration display) to check to con-
firm that the set functions are enable.
C. Network setting
Perform the setting below according to the user environment.
• (Network Settings/ Protocol settings menu) IP Address
• (Network Settings/ Services Settings menu) DNS
When a proxy server is used:
• (Application Settings/ Web Browser Settings menu)
Place a check mark in "Use Proxy Server".
• (Network Settings/ Proxy Setting menu)
• Proxy Server Address
• User Name
• Port Number
• Address without Using Proxy
(Enter all the authenticated LAN addresses being used by
using semicolons to separate.)
D. Operation check
Actually access a web site to check the operation.
No. Name Quantity
1 Operation manual (CD-ROM) 1
2 Product key sheet 1
