MX-M264U MX-HD12 (HARD DISK EXPANSION KIT) 21 – 3
5) Turn ON the main power switch and the operation panel power
switch.
6) Check to confirm that the machine is booted normally.
Check to confirm that the E7-03 error does not occur.
Wait until the display of "Wait for a while" disappears.
NOTE: While "Wait for a while" is displayed, never turn OFF
the power.
F. Firmware version up
1) Use SIM22-5 to confirm that the version is displayed in the
firmware and the watermark.
2) Write the data backed up in the procedure E-2) into the SD
card.
Enter the SIM56-12 mode, and press [EXECUTE] key and
[YES] key.
When the backup operation is completed, "COMPLETE" is dis-
played. Check to confirm the display.
3) Use SIM49-1 to upgrade the firmware to the latest version.
4) Use SIM66-10 to clear the FAX and image send image mem-
ory. (Ensure consistency between the HDD data and the
image data memory.)
G. Shield plate and rear cabinet attachment
1) Attach the shield plate.
2) Attach the rear cabinet.
4. User data restore
NOTE: When the user data were backed up in the procedure 2, the
user data must be restored.
When a HDD option is installed to a machine which has
been not used, the procedure is not required.
1) Use SIM56-2 to restore the data which has been backed up in
the procedure 2-1).
Insert the USB memory into the USB connector in the machine
operation section. Enter the SIM56-2 mode, select
[EEPROM&SD IMPORT] and press [EXECUTE] key and
[YES] key.
When the backup operation is completed, "COMPLETE" is dis-
played. Check to confirm the display.
2) Use the storage backup function to restore the address book
data backed up in the procedure 2-2).
3) Use the device cloning function to restore the data backed up
in the procedure 2-2).
5. Operation check
1) Check the machine operations.
Check to confirm that the copy operation is executed normally.
To Next Page
