MX-M264U CONFIGURATION 1 – 1
MX-M264U
Service Manual
[1] CONFIGURATION
1. System diagram
MX-M264N/M314N/M354N
MX-M264U/M314U/M354U
DIGITAL MULTIFUNCTIONAL
SYSTEM
MX-FN23
FINISHER
MX-TR11
JOB SEPARATOR
MX-TE10
EXIT TRAY UNIT
MX-DE17
500 SHEET PAPER
DRAWER
MX-DE18
2x500 SHEET PAPER
DRAWER
MX-DS17
HIGH STAND
MX-DS16
LOW STAND
MX-PK11
PS3 EXPANSION KIT
MX-PF10
BARCODE FONT KIT
MX-PB15
PRINTER EXPANSION KIT
MX-FX11
FACSIMILE EXPANSION
KIT
AR-SU1
STAMP UNIT
MX-FR37U
DATA SECURITY KIT
MX-FWX1
INTERNET FAX EXPANSION
KIT
MX-NSX1
NETWORK SCANNER
EXPANSION KIT
MX-HD12
HARD DISK EXPANSION KIT
MX-US50
SHARPDESK 50 LICENSE
KIT
MX-UN1HA
Sharp OSA Network Scanner
Tool 100 License Kit
MX-KB14
KEYBOARD
MX-USX1
SHARPDESK 1 LICENSE
KIT
MX-USX5
SHARPDESK 5 LICENSE
KIT
MX-US10
SHARPDESK 10 LICENSE
KIT
MX-USA0
SHARPDESK 100 LICENSE
KIT
MX-AMX1
APPLICATION
INTEGRATION MODULE
MX-AMX2
APPLICATION
COMMUNICATION MODULE
MX-AMX3
EXTERNAL ACCOUNT
MODULE
MX-SCX1
STAPLE CARTRIDGE
AR-SV1
STAMP CARTRIDGE
MX-UN01A
Sharp OSA Network Scanner
Tool 1 License Kit
MX-UN50A
Sharp OSA Network Scanner
Tool 50 License Kit
MX-UN10A
Sharp OSA Network Scanner
Tool 10 License Kit
MX-UN05A
Sharp OSA Network Scanner
Tool 5 License Kit
MX-RP15
REVERSING SINGLE PASS
FEEDER
MX-VR11
DOCUMENT COVER
