Sharp MX-M314N Service Manual

MX-M264U SPECIFICATIONS 2 – 2
G. Paper feed section
(1) Basic specifications
(2) Extra paper capacity
Scanner Single: 50-sheet/min.
(200 x 200dpi, 1bit)
Double: 20-page/min.
(200 x 200dpi, 1bit)
Single: 50-sheet/min.
(200 x 200dpi, 8bit)
Double: 20-page/min.
(200 x 200dpi, 8bit)
Original setup
direction
Upward standard (1 to N feeding standard)
Original standard
position
Center standard (Rear one-side standard for
random feeding)
Original transport
method
Sheet-through method
Original size Standard size
Inch-1: 11" x 17", 8.5" x 14", 8.5" x 11", 8.5" x 11"R,
5.5" x 8.5", A3, A4
Inch-2: 11" x 17", 8.5" x 13", 8.5" x 11", 8.5" x 11"R,
5.5" x 8.5", A3, A4
Inch-3: 11" x 17", 8.5" x 13.4", 8.5" x 11",
8.5" x 11"R, 5.5" x 8.5", A3, A4
AB-1: 11" x 17", 8.5" x 14", 8.5" x 11", A3, B4, A4,
A4R, B5, B5R, A5
AB-2: 11" x 17", 8.5" x 13", 8.5" x 11", A3, B4, A4,
A4R, B5, B5R, A5
AB-3: 11" x 17", 8.5" x 13", 8.5" x 11", A3, B4, A4,
A4R, A5, 8K, 16K, 16KR
AB-4: 11" x 17", 8.5" x 13.4", 8.5" x 11", A3, B4, A4,
A4R, B5, B5R, A5
AB-5: 11" x 17", 8.5" x 13.5", 8.5" x 11", A3, B4, A4,
A4R, B5, B5R, A5
Long
paper
1000 mm (Monochrome binary only)
Internet Fax 600 x 600 dpi: Max. 800 mm.
When scan 400 dpi or more, long paper
is not available.
Mix paper feed
(Same series,
same width paper)
Enabled
Random feeding
(feeding of different
types / different
widths)
Enabled
Only the following combinations of 2 size types are
allowed:
A3 and B4; B4 and A4R; A4 and B5; B5 and A5;
and 11-inch and 8.5-inch. AMS available. 2-sided
scanning is disabled during random feeding.
Original copy
weight
Single:
Thin paper: 9 - 13 lb bond (35 - 49 g/m
2
)
Plain paper: 13 - 32 lb bond (50 - 128 g/m
2
)
* Thin paper mode (39 pages/minute
(A4, 8.5" x 11", 600 x 400dpi) / 26 pages/minute
(A4, 8.5" x 11", 600 x 600dpi) is set up for the thin
paper.
Duplex: 13 - 28 lb bond (50 - 105 g/m
2
)
Max. loading
capacity of
documents
Max. 100 sheets (21lbs Bond, 80g/m
2
), or Max.
height: 1/2 inch, 13mm or less
Un-acceptable
originals for
feeding.
Transparency, second original paper, tracing paper,
carbon paper, thermal paper, paper with wrinkles,
folds, or breakage, pasted paper, cutout document,
document printed with ink ribbon, documents with
perforation other than 2- or 3-holes (Perforated
document by punch unit is allowed.)
Detection Yes
Paper detection
size
Auto detection
Inch-1: 11" x 17", 8.5" x 14", 8.5" x 11", 8.5" x 11"R,
5.5" x 8.5", A3, A4
Inch-2: 11" x 17", 8.5" x 13", 8.5" x 11", 8.5" x 11"R,
5.5" x 8.5", A3, A4
Inch-3: 11" x 17", 8.5" x 13.4", 8.5" x 11",
8.5" x 11"R, 5.5" x 8.5", A3, A4
AB-1: 11" x 17", 8.5" x 14", 8.5" x 11", A3, B4, A4,
A4R, B5, B5R, A5
AB-2: 11" x 17", 8.5" x 13", 8.5" x 11", A3, B4, A4,
A4R, B5, B5R, A5
AB-3: 11" x 17", 8.5" x 13", 8.5" x 11", A3, B4, A4,
A4R, A5, 8K, 16K, 16KR
AB-4: 11" x 17", 8.5" x 13.4", 8.5" x 11", A3, B4, A4,
A4R, B5, B5R, A5
AB-5: 11" x 17", 8.5" x 13.5", 8.5" x 11", A3, B4, A4,
A4R, B5, B5R, A5
Paper feeding
direction
Right hand feeding
Finish stamp Option
Reliability MCBJ/MCBF: Same as the main unit
Life Same as the main unit
Power Source Provided from the main unit
Dimensions W 580 x D 465 x H 155 mm, W 22-54/64 x D 18-20/
64 x H 6-7/64 in.
Weight Approx. 7.3kg, Approx. 16.1 lbs
Outer color Warm gray/ Pastel white (2 toned color)
Optional detection Auto detection supported
Installation /
Maintenance
Should be installed by the service technician easily
Packaged items Glass cleaner (must be storable in the RSPF)
Type Standard 2-stage paper feed tray + multi manual paper feed
tray
Full option 4-stage paper feed tray + multi manual paper feed
tray
Dehumidifying
heater
N/A
Tray Tray 1 Tray 2
Multi
Bypass Tray
Paper
capacity
Standard
paper
(80g/m
2
)
500 sheets 500 sheets 100 sheets
Paper size Refer to “Size of paper which can be fed”.
Paper size detection No
(Guide adjustment and size input)
Yes
Paper type setting Refer to “Size of paper which can be fed”.
Changing of paper
size
Switched by the user Switched by
the user
(Guide
adjustment)
Universal handle Yes ---
Default
paper
size
setting
Inch
system
8.5" x 11" ---
AB
system
A4 ---
Detection of
remaining paper
N/A (Only paper availability is detected)
Paper size display
window
Yes ---
Paper type Paper feed tray Manual feed tray
Envelope NA AB system: 10 sheets
Inch system: 5 sheets
Transparency NA 40 sheets
Heavy paper NA 30 sheets (Max. 200g/m
2
)
Tab paper NA 30 sheets (Target)
Others NA 1 sheet

Sharp MX-M314N Specifications

General

Print Technology	Laser
Print Speed	31 ppm
Standard Paper Capacity	1100 sheets
Duplex Printing	Yes
Max Scan Resolution	600 x 600 dpi
Copy Speed	31 cpm
Max Copy Resolution	600 x 600 dpi
Fax Capability	Optional
Network Connectivity	Ethernet
Functions	Print, Copy, Scan, Fax
Warm-up Time	20 seconds
Fax Transmission Speed	33.6 Kbps
Max Paper Size	A3
Scanner Type	Color
Display	7-inch color touchscreen
Original Size	A3
Operating System Compatibility	Windows, Mac, Linux
