Sharp MX-M314N Service Manual

MX-M264U CONSUMABLE PARTS 3 – 3
C. STCL/ SRH/ SRS/ SRSSC/ SBI/ Agent
* The other maintenance parts than the above are supplied as service parts.
3. Developer/Drum life end definition
• When the developer/drum counter reaches the specified level.
• When the developer/drum rpm reaches the specified level.
When either of the above reached the specified level, it is judged as life end.
In an actual case, when correction or warm-up operation is performed as well as output operation, the developer and the drum rotates.
Therefore, the developer/drum consuming level cannot be determined only by the copy/print quantity. When, therefore, the rpm reaches the
specified level, it is judged as life end.
To check the drum and developer life, use SIM22-1/SIM22-13.
No. Item Content Life Model name Remarks
1 Upper heat roller kit Upper heat roller x 1 150K AR-310UH
Fuser gear x 1
Upper heat roller bearing x 2
Upper cleaning pad x 1
Fusing separation pawl (upper) x 4
Thermistor cleaning pad x 2
2 Lower heat roller kit Lower heat roller x 1 300K MX-311LH
Fusing separation pawl (lower) x 4
Fuser bearing (lower) x 2
3 150K PM kit Drum separation pawl unit x 2 150K MX-311KA
Transfer roller unit x 1
DV blade x 1
DV side sheet F x 1
DV side sheet R x 1
Toner filter unit x 1
4 MC unit MC unit x 10 26cpm: 75K (x 10)
31/35cpm: 100K (x 10)
MX-311MC
5 Cleaner blade Cleaner blade x 10 26cpm: 75K (x 10)
31/35cpm: 100K (x 10)
MX-311CB
6 Drum frame unit Drum frame unit x 1 26cpm: 225K
31/35cpm: 300K
MX-311DU * The life of the toner reception seat
attached to the drum frame is 300K, and it
can be used up to 3 times.
(Supplied as a drum frame unit.)
7 Staple cartridge Staple cartridge x 3 5000 staples x 3 MX-SCX1
Developer/drum counter
Number of rotations
(Rotations)
Developer/drum 26cpm model 31/35cpm model 550K
75K 100K

Sharp MX-M314N Specifications

General

Print Technology	Laser
Print Speed	31 ppm
Standard Paper Capacity	1100 sheets
Duplex Printing	Yes
Max Scan Resolution	600 x 600 dpi
Copy Speed	31 cpm
Max Copy Resolution	600 x 600 dpi
Fax Capability	Optional
Network Connectivity	Ethernet
Functions	Print, Copy, Scan, Fax
Warm-up Time	20 seconds
Fax Transmission Speed	33.6 Kbps
Max Paper Size	A3
Scanner Type	Color
Display	7-inch color touchscreen
Original Size	A3
Operating System Compatibility	Windows, Mac, Linux
