Sharp MX-M314N Service Manual

MX-M264U SPECIFICATIONS 2 – 1
MX-M264U
Service Manual
[2] SPECIFICATIONS
1. Basic specifications
A. Engine Specification
B. Engine speed (ppm)
Tray 1 - 4
Manual paper feed
C. Printable area
D. Engine resolution
*1: Resolustion: 600dpi (default)
*2: The dither and error diffusion methods using 8bit input will be
performed.
E. Scanner section
(1) Resolution/Gradation
(2) Document table
F. Document feeder
Photo conductor OPC (Diameter: 30mm)
Recording Electronic photo (Laser)
Development Dry-type dual-component magnetic
brush development
Charging Charged saw-tooth method
Transfer Transfer roller
Separation Separation claw method
Cleaning Counter blade
Fusing Heat roller
Waste toner disposal Toner cartridge collection
Toner supply during operation N/A
Outer color Pastel white (Natural wave pattern)
Paper size
26cpm
machine
31cpm
machine
35cpm
machine
A3 15 17 20
11" x 17" 14 17 19
8K 16 19 21
B4, 8.5" x 13" 16 20 22
8.5" x 14" 16 20 22
A4, B5, 8.5" x 11", 5.5" x 8.5", 16K, A5
(B5 cannot be applied to the 2-stage
paper feed tray.)
26 31 35
A4R, 16KR, 8.5" x 11"R, 18 24 27
B5R 21 24 30
Paper size
26cpm
machine
31cpm
machine
35cpm
machine
A3 14 17 18
11" x 17" 14 16 17
8K 15 18 19
B4 16 19 20
8.5" x 13" 17 20 22
8.5" x 13.5", 8.5" x 13.4" 16 19 21
8.5" x 14" 16 19 20
A4, B5, 8.5" x 11", 5.5" x 8.5", 16K, A5 23 27 29
A4R, 8.5" x 11"R, 19 22 24
B5R 21 24 26
A6R 23 27 29
Extra 14 16 17
Custom 14 16 17
A3 Wide N/A 16K 187 x 262mm
A3 289 x 412mm 12 x 18 N/A
B4 242 x 356mm 11" x 17" 271 x 424mm
A4 202 x 289mm 8.5" x 14" 208 x 348mm
B5 168 x 249mm 8.5" x 13" 208 x 322mm
A5 140 x 202mm Executive 183 x 259mm
A6R 92 x 140mm 8.5" x 11" 208 x 271mm
8K 262 x 382mm 5.5" x 8.5" 132 x 208mm
8.5" x 13.5" 212 x 336mm 8.5" x 13.4" 212 x 333mm
Custom Min.: 96mm x 141mm; Max.: 297mm x 432mm
Max. range AB system: 416 x 293mm
(When the resolution is 600dpi: 9826dot x 6920dot)
Inch system: 428 x 275mm
(When the resolution is 600dpi: 10110dot x 6496dot)
Void Area /
Image Loss
Top: 4mm or less
Bottom: 4mm or less
FR total: 6mm or less
Resolution*
1
Copy Writing
600 x 600dpi
Print Writing
600 x 600dpi
1,200 x 600dpi (PCL/PS)
Gradation *
2
(256 levels)
Copy Writing
600 x 600dpi x 1bit
Print Writing
Sharp Advanced Printing Language:
600 x 600dpi x 1bit
PCL:
600 x 600dpi x 1bit
1,200 x 600dpi x 1bit
PS:
600 x 600dpi x 1bit
1,200 x 600dpi x 1bit
Scanning
Resolution (dpi)
Monochrome
Platen 600 x 600dpi
600 x 400dpi
600 x 300dpi (default)
RSPF 600 x 600dpi
600 x 400dpi (default)
Exposure lamp White LED
Reading gradation 10bit
Output gradation BW: 1bit
Grayscale: 8bit
Full Color: each color RGB 8bit
Type Document table fixed system (Flat bed)
Scanning area 297 x 432mm
Original standard
position
Left rear reference
Detection Yes
Detection size Automatic detection (Detection types can be
changed in the system settings)
Dehumidifying
heater
(Scanner section)
Supplied as a service parts
Type RSPF (Reversing single pass feeder)
Scan speed Monochrome
(A4/8.5" x 11")
Color (A4/8.5" x 11")
Copy Single:
50-sheet/min.
(600 x 400dpi, 4bit)
36-sheet/min.
(600 x 600dpi, 4bit)
Double:
20-page/min.
(600 x 400dpi, 4bit)
17-page/min.
(600 x 600dpi, 4bit)
NA
FAX Single: 50-sheet/min.
(200 x 200dpi, 1bit)
Double: 20-page/min.
(200 x 200dpi, 1bit)
NA
Internet FAX Single: 50-sheet/min.
(200 x 200dpi, 1bit)
Double: 20-page/min.
(200 x 200dpi, 1bit)
NA

Sharp MX-M314N Specifications

General

Print Technology	Laser
Print Speed	31 ppm
Standard Paper Capacity	1100 sheets
Duplex Printing	Yes
Max Scan Resolution	600 x 600 dpi
Copy Speed	31 cpm
Max Copy Resolution	600 x 600 dpi
Fax Capability	Optional
Network Connectivity	Ethernet
Functions	Print, Copy, Scan, Fax
Warm-up Time	20 seconds
Fax Transmission Speed	33.6 Kbps
Max Paper Size	A3
Scanner Type	Color
Display	7-inch color touchscreen
Original Size	A3
Operating System Compatibility	Windows, Mac, Linux
