ADJ 16 Finisher adjustments
(alignment, staple position)
This adjustment must be performed in the following cases:
* When the finisher is disassembled.
* When the finisher control PWB is replaced.
* When the alignment is improper.
* When the staple position is shifted.
1) Enter the SIM 3-10 mode.
2) Select an adjustment target item with the scroll key.
Inner finisher
3) Enter an adjustment value and press [OK] key.
4) Cancel the simulation, make a copy in the mode including the
adjustment target, and check the adjustment result.
Item/Display Content
Setting
range
Default
value
A FPAM ADJUST Alignment width adjustment 40 - 60 50
B FDRLM ADJUST Paper exit roller descending
position adjustment
40 - 60 50
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
),1,6+(5$'-8670(17


$˖
˷˹
˖)3$0$'-867
$˖
˖)'5/0$'-867
%˖
2.
