Sharp MX-M314N Service Manual

MX-M264U DISASSEMBLY AND ASSEMBLY 10 – 15
6. Side door unit
A. Transport roller unit
* Check that two springs are securely inserted into the transfer
roller unit bosses.
B. Transport roller
C. DUP transport roller
