MX-M264U VARIOUS STORAGE DATA HANDLING 11 – 1
MX-M264U
Service Manual
[11] VARIOUS STORAGE DATA HANDLING
1. HDD/SD card memory map
A. HDD partition
Option HDD installed
HDD size = 160GB (Actual size 149GB)
B. HDD data contents
Option HDD installed
No. File system Stored data NOTE
I-1 Image data Image data (ERDH/Temporary storage) 1000 documents, 3000 images
I-2 Image data Image data (Document filing) 3000 documents, 20000 images
I-3 Image data Not available Not used
I-4 Image data FAX/Internet Fax receive images
L-1 Not available System storage data (Address book, image send system registration data (sender's
information, meta data, etc.), FSS collection data)
S-1 Universal Download font
User macro
Database system file
System log
System setting data (Backup)
S-2 Universal Document filing (Database)
Job log (Database)
Job completion list
S-3 Universal Not available Not used
S-4 Universal Not available Not used
S-5 Universal Spool area for printer
S-6 Universal Application work area (User file used in USB direct print)
S-7 Universal Not available Not used
S-8 Universal Not available Not used
S-9 Universal Data backup when installing DSK (User data (Address book, account information))
S-10 Universal e-manual
Watermark
L-2 Universal Not available Not used
Outer
tracks
Inner
tracks
offset
(GB)
0
10
20
30
40
50
60
70
80
90
100
110
120
130
140
0123456789
[GB]
[GB]
[I-1] 14GB
[I-2] 72GB
[S-1] 2.5GB
[S-5] 16GB
[S-6] 4GB
[S-9] 6GB
[S-3] 2GB Not used
[S-7] 2GB Not used
[L-2] 1GB
[S-8] 16GB Not used
[S-10] 8GB
[S-4] 2GB Not used
[I-3] 1GB
Not used
[I-4] 1GB [L-1] 1GB
[S-2]
0.5GB
