Sharp MX-M314N Service Manual

MX-M264U DISASSEMBLY AND ASSEMBLY 10 – 14
Installation * Install so that the cam transmit arm (1) comes under
the roller arm (2).
(2) Reverse sensor
(3) Separation sheet
* Slightly apply grease GP501MR (UKOG-0012QSZZ) around the
axis. One rice grain for each.
(4) Clutch/solenoid
Clutch
Solenoid
Clutch
1
2
2
1
4
3
L
O
C
K
1
3
2
1)
2)
3)
2
1
1
2
2
3
1
2
A
A
A
A
A
A
A

Sharp MX-M314N Specifications

General

Print Technology	Laser
Print Speed	31 ppm
Standard Paper Capacity	1100 sheets
Duplex Printing	Yes
Max Scan Resolution	600 x 600 dpi
Copy Speed	31 cpm
Max Copy Resolution	600 x 600 dpi
Fax Capability	Optional
Network Connectivity	Ethernet
Functions	Print, Copy, Scan, Fax
Warm-up Time	20 seconds
Fax Transmission Speed	33.6 Kbps
Max Paper Size	A3
Scanner Type	Color
Display	7-inch color touchscreen
Original Size	A3
Operating System Compatibility	Windows, Mac, Linux
