MX-M264U SIMULATION 6 – 76
66-36
Purpose
Operation test/Check
Function (Purpose)
Used to check send and receive data from
the MODEM controller to the MFP control-
ler or the data line or the command line
individually.
Section
FAX
Operation/Procedure
1) When the machine enters Simulation 66-36, the following
screen is displayed.
2) Operation check
Select an item to be checked on the screen.
MFP controller I/F check item table
66-39
Purpose
Setting
Function (Purpose)
Used to check and change the destination
setting saved in EEPROM of the FAX BOX.
Section
FAX
Operation/Procedure
1) When the machine enters the simulation, the currently set des-
tination button is highlighted. (In the default state, JAPAN is set
as the destination.)
2) Select a destination button to set the destination. (In this
example, USA/CANADA is selected.) The selected button is
highlighted and the previously selected button returns to the
normal display.
* When the destination button is changed, the new destination
setting is saved to EEPROM of the FAX BOX.
Destination setting table
66-42
Purpose
Setting
Function (Purpose)
Used to rewrite the program to power con-
trol installed in the FAX BOX.
Section
FAX
Operation/Procedure
1) Press [EXECUTE] button.[EXECUTE] button is highlighted
and YES] and [NO] buttons become active.
2) Press [YES] button.
The power control program is rewritten.
3) When rewriting of the power control program is normally com-
pleted, "OK" is displayed and [EXECUTE] button returns to the
normal display, and [YES] and [NO] buttons gray out.
66-43
Purpose
Setting
Function (Purpose)
Used to write the adjustment value into the
power control installed in the FAX BOX.
Section
FAX
Operation/Procedure
1) When the machine enters Simulation 66-43, the following
screen is displayed.
* Use scroll keys to select the select item of the power control
adjustment value.
2) When [EXECUTE] key is pressed, it is highlighted and writing
to the power control is executed. When writing is normally
completed, "OK" is displayed. When it is failed, "NG" is dis-
played.
3) After completion of writing, [EXECUTE] key returns to the nor-
mal display.
Set range and default value of each set value
66-61
Purpose
Setting
Function (Purpose)
Used to display the FAX-related soft SW
(151 - 250) on the LCD to allow changing
the soft SW while checking with the LCD.
Section
FAX
Operation/Procedure
1) Enter the [SW NO] with 10-key.
2) Press [DATA] button.
The soft SW data entered in procedure 1) is displayed.
3) Enter the number corresponding to the bit to be changed with
10-key.
*[1] ï‚® [0]
[0] ï‚® [1]
4) When [EXECUTE] button is pressed, it is highlighted and the
setting is saved.
66-62
Purpose
Backup
Function (Purpose)
Used to import the FAX receive data into a
USB memory in PDF file type.
Section
FAX
Operation/Procedure
1) Insert the USB memory into the main unit.
2) Select data to be imported.
3) Press [EXECUTE] key.
Execute import of data selected in procedure 2).
When the operation is completed normally, [COMPLETE] is
displayed. In case of an abnormal end, [ERROR] is displayed.
MFP  MDMC (DATA once)
Data line Once
MFP ï‚® MDMC (DATA once)
Data line Once
MFP  MDMC (DATA repeat)
Data line Repeat
MFP ï‚® MDMC (DATA repeat)
Data line Repeat
MFP  MDMC (CMD once)
Command line Once
MFP ï‚® MDMC (CMD once)
Command line Once
MFP  MDMC (CMD repeat)
Command line Repeat
MFP ï‚® MDMC (CMD repeat)
Command line Repeat
JAPAN U.S.A/CANADA EUROPE AUSTRALIA
CHINA ASIA&OTHERS
Item Set range Default value
A CI_LEVEL_JUDGE 2 to 15 6
B CI_CYCLE_MIN 1 to 254 10
C CI_CYCLE_MAX 2 to 255 142
D CI_COUNT 2 to 15 3
E RES_3.3V_LEVEL_JUDGE 2 to 15 15
F EXHS_LEVEL_JUDGE 2 to 225 240
G RHS_LEVEL_JUDGE 2 to 15 2
H SON_TIMEOUT 1 to 127 20
Error display Content
ERROR: NO USB MEMORY DEVICE No USB memory installed
ERROR: NO IMAGE DATA No image data
ERROR Other errors
