Sharp MX-M620N

MX-M700N SIMULATION 7 – 50
(Table 2)
(Table 3)
50-6
Purpose
Adjustment
Function (Purpose)
Used to adjust the copy image position and
void area (image loss) on print paper in the
copy mode. (The similar adjustment can be
performed with SIM 50-7 (simple method).)
(SPF mode)
Section
—
Operation/Procedure
(Lead edge image loss adjustment) (Table 1)
1) Set the adjustment values for leading edge image loss for the
front and back sides as follows:
(Standard set value)
Lead edge image loss: 1.5mm (LEAD: 15)/Paper lead edge
void: 3.5mm (DENA: 35)
* Set the adjustment value of LEAD to 15. (Enter 15 as the
adjustment value of LEAD EDGE, and press [P] key.)
2) Make a duplex copy at 100% with the SPF, and check that the
lead edge (image loss) is 1.5mm either on the front surface
and the back surface. (Select the duplex mode in the paper
selection mode of SIM 50-6.) (Table 3) (Enter 100 as the copy
magnification ratio set value (MAGNIFICATION), and press
[START] key.)
If an acceptable result is not obtained, do the following steps.
3) Change the adjustment values of SIDE1 and SIDE2, and per-
form the adjustment. (Change the adjustment values of SIDE1
and SIDE2, and press [START] key.)
SIDE1: SPF front surface document lead edge scan position
adjustment value
SIDE2: SPF back surface document lead edge scan position
adjustment value
(Shift for the adjustment value change: 0.1mm/step)
(The image scan start timing is determined with the detection
timing of the document lead edge by the detector SPPD4.)
Repeat procedures 2) and 3) until a satisfactory result is obtained.
(Trailing edge image loss adjustment)
1) Use the SPF at 100% to make a duplex copy, and check that
the rear edge image loss is 1.5mm on the front and the back
surfaces. (Select the duplex mode in the paper selection mode
of SIM 50-6.) (Enter 100 as the copy magnification ratio set
value (MAGNIFICATION), and press [START] key.)
If an acceptable result is not obtained, do the following steps.
2) Repeat the process of changing the (TRAIL EDGE) adjust-
ment value and then pressing the [START] key. until attaining
an acceptable level.
Repeat the above adjustments until an acceptable result is
obtained.
(Front/rear frame direction image loss adjustment)
Set the adjustment value of the front surface and the back surface
(FRONT/REAR) to 20. (Enter 20 as the adjustment value of
FRONT/REAR, and press [P] key.)
Note that changing this adjustment value shifts the image position
in the front/rear frame direction.
NOTE: When [P] key is pressed after entering an adjustment value
in this simulation, the adjustment value is set. When
[START] key is pressed, the adjustment value is set and
copying is performed. (Table2)
(Copy condition setting in this simulation)
* To select paper (paper feed tray), perform the following proce-
dures.
1) Enter 0 with 10-key.
2) Press [START] key. (The mode is changed to the paper feed
tray selection mode.)
3) Enter the number corresponding to the paper feed tray to be
used with 10-key. (Table 3)
4) Press [START] key. (The paper feed tray is selected.)
* The copy magnification ratio can be set with the following proce-
dures.
1) Enter 2 with 10-key.
2) Press the [START] key.
3) Enter the copy magnification ratio with 10-key.
4) Press the [START] key.
(Table 1)
13 TRAY 4 Tray 4 adjustment - 50 50
14 BPT Manual feed tray
adjustment
-
15 LCC Side LCC adjustment -
16 ADU Adjustment when
paper is fed again
from ADU
-
(Void set value)
17 LEAD_E
DGE
(DENA)
Lead edge void set
value
0 - 99
35 35
18 TRAIL_
EDGE
(DENB)
Rear edge void
adjustment value
19 FRONT/
REAR
Front/Rear void
adjustment value
Normal display NOW PRINTING.
ERROR display Door open DOOR OPEN.
Jam JAM
Paper empty PAPER EMPTY.
1TRAY1 TRAY1
2TRAY2 TRAY2
3TRAY3 TRAY3
4TRAY4 TRAY4
5 BPT Manual paper feed
6 LCC Side LCC
Item
Setting
range
Default
55/62
(ppm)
70
(ppm)
1
2
SIMULATION 50-5
LEAD EDGE ADJUSTMENT. SELECT 0-20, AND PRESS START.
0.TRAY SELECT 1 1.PRINT START
(ADJUSTMENT DATA)
LEAD EDGE: 2.RRCB 50 20.SIDE2 ADJ. 50
RESIST: 3.T1 50 4.T2 50 5.T3 50 6.T4 50
7.BPT 50 8.LCC 50 9.ADU 50
OFF CENTER: 10.T1 50 11.T2 50 12.T3 50 13.T4 50
14.BPT 50 15.LCC 50 16.ADU 50
(VOID SETTING) 17.LEAD_EDGE(DENA) 50
18.TRAIL_EDGE(DENB) 30 19.FRONT/REAR 30
Setting range 25 - 200 (%)
Item
Setting
range
Default
0 TRAY SELECT Paper feed tray
selection
1 - 6 -
1 COPY START Copy START (Default) - -
2 MAGNIFICATION Print magnification
ratio
25 -
200%
-
(Lead edge adjustment value)
3 SIDE1 Front surface
document scan start
position adjustment
value
0 - 99 50
4 SIDE2 Back surface
document scan start
position adjustment
value
: '07 Feb 15
