Sharp MX-M620N

MX-M700N OTHERS 12 – 14
B. Inserter (AR-CF2) paper jam judgment conditions
*1) The take-up position is 30mm downstream from the vertical path transport roller.
*2) The reverse stop position is 20mm downstream from the reverse sensor.
JAM code Name
JAM detection method
JAM judge distance
JAM detection start trigger JAM judge detector
REG_SEN_N Resist sensor not-reached JAM Separation start Resist sensor ON (Distance from pick descending start to
resist sensor ON) ✕ 5
REG_SEN_S Resist sensor remaining JAM Transport start from the
take-up position (*1)
Resist sensor OFF Max. document length (WLT) - (Resist
sensor OFF to take-up position) + 200mm
TIM_SEN_N Timing sensor not-reached JAM Resist sensor ON Timing sensor ON Distance from resist sensor ON to timing
sensor ON + 200mm
TIM_SEN_S Timing sensor remaining JAM Resist sensor OFF Timing sensor OFF Distance from resist sensor OFF to timing
sensor OFF + 200mm
HI_SEN_NI Paper exit sensor remaining JAM
(Inserter paper feed)
Timing sensor ON Reverse sensor ON Distance from timing sensor ON to paper
exit sensor ON + 200mm
HI_SEN_NP Paper exit sensor notreached JAM
(Main unit paper feed)
Main unit paper exit
command receive
Reverse sensor ON Distance from main unit side to paper exit
sensor ON + 500mm
HI_SEN_S Paper exit sensor remaining JAM
(Main unit paper feed)
After passing by 20mm from
the paper exit sensor ON
Paper exit sensor OFF Max. document length (WLT) + 200mm
Paper exit sensor remaining JAM
(Inserter paper feed)
Timing sensor OFF Paper exit sensor OFF Distance from timing sensor OFF to paper
exit sensor OFF + 200mm
H_SEN_NIN Reverse sensor notreached JAM
(When entering the reverse path)
Timing sensor ON Reverse sensor ON Distance from timing sensor ON to
reverse sensor ON + 100mm
H_SEN_NOUT Reverse sensor notreached JAM
(When exiting from the reverse path)
Switchback start Reverse sensor ON Distance from reverse stop position (*2) to
reverse sensor ON + 100mm
H_SEN_SIN Reverse sensor remaining JAM
(When entering the reverse path)
Timing sensor OFF Reverse sensor OFF Distance from timing sensor OFF to
reverse sensor OFF + 100mm
H_SEN_SOUT Reverse sensor remaining JAM
(When exiting from the reverse path)
After passing 20mm from the
reverse sensor ON
Reverse sensor OFF Max. Document length (WLT) + 100mm
JAM code Content
JAM detection method
JAM judgment time
(Stacker:
LTR horizontal size
Saddle: LTR vertical size)
JAM detection timer
start trigger
JAM judge detector
Common to 55/62,
70PPM MODELS
(Main unit paper exit speed:
Stacker: 800mm/s
Saddle: 420mm/s)
FES_N FINISHER entry port remaining JAM Main unit paper exit
command receive
The paper entry sensor is not turned
ON within the specified time.
500ms
FES_S FINISHER entry port remaining JAM Entry port sensor ON The paper entry sensor is not turned
OFF within the specified time.
540ms
FINISHER buffer sensor notreached
JAM
Entry port sensor ON The buffer sensor is not turned
ONwithin the specified time.
688ms
FINISHER buffer sensor remaining
JAM
Buffer sensor ON The buffer sensor is not turned OFF
within the specified time.
540ms
FINISHER paper exit sensor not-
reached JAM
Entry port sensor ON The paper exit sensor is not turned ON
within the specified time.
Straight path transport: 453ms
Buffer path transport: 815ms
FINISHER paper exit sensor
remaining JAM
Entry port sensor ON The paper exit sensor is not turned
OFF within the specified time.
840ms
FFPS_N FINISHER saddle transport path
sensor remaining JAM
Entry port sensor ON The saddle transport path sensor is
not turned ON within the specified
time.
914ms
FFPS_S FINISHER saddle transport path
sensor remaining JAM
Saddle transport path
sensor ON
The saddle transport path sensor is
not turned OFF within the specified
time.
996ms
FINISHER saddle paper exit sensor
not-reached JAM
Folding edge sensor ON
(Completion of thrust
operation)
The saddle transport sensor is not
turned ON though paper is transported
in the specified distance.
180mm
(Twice as much as
the normal distance)
FINISHER saddle paper exit sensor
remaining JAM
Saddle paper exit sensor
ON
The saddle paper exit sensor is not
turned OFF though paper is
transported in the specified distance.
209.25mm
(1.5 times as much as
the normal distance)
FEXIT_S FINISHER bundle exit remaining
JAM
Start of bundle exit to the
stack tray
The staple tray sensor is not turned
OFF within the specified time.
1000ms
FSTPL FINISHER Stacker staple JAM Start of stacker stapling When the staple HP sensor does not
sense ON within the specified time
from staple HP sensor OFF in stapling
process, and when the staple HP
sensor detects ON in reverse rotation
after stopping the stapler.
500ms
