Sharp MX-M620N - Maintenance Parts List

MX-M700N CONSUMABLE PARTS 3 – 2
F. Middle East/Philippine
G. Ta iwan
2. Maintenance parts list
A. U.S.A, Canada
No. Part name Content Life Model name Packing Remark
1 Toner cartridge (Black) Toner cartridge (Black)
(Toner; Net weight 1815g) With IC chip
x 10 830k (83k x 10) AR-621ET 1 * Life setting by A4 6%
document
2 Developer (Black) Developer (Black)
(Developer; Net weight 725g)
x 10 62/70ppm: 1500k
(150k x 2bags x 5)
55ppm: 1250k
(125k x 2bags x 5)
AR-620CD 1 Two bags needed.
3 Drum OPC drum x 1 62/70ppm: 300k
55ppm: 250k
AR-620DR 10
No. Part name Content Life Model name Packing Remark
1 Toner cartridge (Black) Toner cartridge (Black)
(Toner; Net weight 1815g) With IC chip
x 10 830k (83k x 10) AR-621ET 1 * Life setting by A4 6%
document
2 Developer (Black) Developer (Black)
(Developer; Net weight 725g)
x 10 62/70ppm: 1500k
(150k x 2bags x 5)
55ppm: 1250k
(125k x 2bags x 5)
AR-620LD 1 Two bags needed.
3 Drum OPC drum x 1 62/70ppm: 300k
55ppm: 250k
AR-620DM 10
No. Part name Content Life Model name Packing Remark
1 Maintenance kit 1 Side seal F
Side seal R
MC cleaning unit
Cleaner blade
Drum separation pawl
Screen grid
Toner reception seal
Charging plate
Paper dust removal unit
DV seal
DV side seal F
DV side seal R
Toner filter
x 1
x 1
x 1
x 1
x 4
x 1
x 1
x 1
x 1
x 1
x 1
x 1
x 1
300K AR-620KA 10
2 Maintenance kit 2 Transfer cleaning roller
Transfer belt
Transfer roller
Transfer gear
x 1
x 1
x 1
x 1
300K AR-620KB 10
3 Upper heat roller kit Upper heat roller
Fusing separation pawl (Upper)
x 1
x 6
300K AR-620UH 10
4 Lower heat roller kit Lower heat roller
Fusing separation pawl (Lower)
x 1
x 4
300K AR-620LH 10
5 Cleaner blade Cleaner blade x 10 300K (x 10) AR-620CB 1 AR-620CB =
(AR-620BL) x 10
6 Cleaning kit Lower CL roller DG2
CL roller SP
CL roller bearing
Auxiliary CL roller SP
CL auxiliary roller DG
Heat CL sheet base N AS
Web roller DG2
Pressure roller DG2
Web bearing
Pressure bearing
Pressure SP
x 10
x 20
x 40
x 20
x 10
x 10
x 10
x 10
x 20
x 20
x 20
300K (x 10) MX-705CR 1 MX-705CR =
(MX-705RC) x 10
7 Fusing unit Fusing UN (Heater lamp 120V) x 1 — MX-705FU1 1
8 Heat roller kit Heat roller
Heat roller bearing
x 1
x 2
300K AR-620HR 10
9 DSPF roller kit DSPF paper feed roller
DSPF pickup roller
DSPF separation roller
x 1
x 1
x 1
100K AR-620DF 10
10 Paper feed roller kit Main unit paper feed roller
Main unit paper feed pickup roller
Main unit paper feed separation roller
x 1
x 1
x 1
100K AR-620RT 10
11 Staple cartridge Finisher staple x 3 5,000 times x 3 SF-SC11 20 Cartridge for AR-F15
(Common with the cartridge
for AR-F11/F12)
12 Staple cartridge Saddle finisher staple x 3 2,000 times x 3 AR-SC3 40 Cartridge for AR-F16
(Common with the cartridge
for AR-F12)
