Sharp MX-M620N

MX-M700N ELECTRICAL SECTION 11 – 18
4. Signal name list
Signal name Name Function/Operation
Connector level Connector
No.
Pin
No.
PWB
name
Remark
“L” “H”
/MIMA Scanner motor control signal
(Phase /A)
Scanner motor control (Phase /A) — — 7 3 SCN
/MIMB Scanner motor control signal
(Phase /B)
Scanner motor control (Phase /B) — — 7 4 SCN
/SLUMB DDSPF paper feed tray lift-up
motor control signal
(Phase /B)
DSPF paper feed tray lift-up motor
control (Phase /B)
——112SCN
/SLUMA DSPF paper feed tray lift-up
motor control signal
(Phase /A)
DSPF paper feed tray lift-up motor
control (Phase /A)
——111SCN
/SPFMA DSPF motor control signal
(Phase /A)
DSPF motor control (Phase /A) — — 12 11 SCN
/SPFMB DSPF motor control signal
(Phase /B)
DSPF motor control (Phase /B) — — 12 15 SCN
/VIDEO Image data signal Image signal to LSU (PCU output) — — 22 23 PCU
38VMON 38V monitor signal Detection of 38V for interlock OFF ON 19 14 PCU
ACMON AC waveform monitor signal SUB power source AC wave high
value monitor (For heater lamp ON
control) (Phase control)
——13PCU
ADD_CCD1 CCD serial data area
identification number (CCD)
Identification of address data and
image data area in CCD serial data
——166SCN
ADD_CCD2 CIS serial data area
identification number (CIS)
Identification of address data and
image data area in CIS serial data
— — 10 13 SCN
ADM1A Duplex (ADU) motor 1
(Upstream side) control signal
(Phase A)
Duplex (ADU) motor 1 (Upstream)
control (Phase A)
——109PCU
ADM1B Duplex (ADU) motor 1
(Upstream side) control signal
(Phase B)
Duplex (ADU) motor 1 (Upstream)
control (Phase B)
——1011PCU
ADM1XA Duplex (ADU) motor 1
(Upstream side) control signal
(Phase /A)
Duplex (ADU) motor 1 (Upstream)
control (Phase /A)
— — 10 10 PCU
ADM1XB Duplex (ADU) motor 1
(Upstream side) control signal
(Phase /B)
Duplex (ADU) motor 1 (Upstream)
control (Phase /B)
— — 10 12 PCU
ADM2A Duplex (ADU) motor 2
(Downstream side) control
signal (Phase A)
Duplex (ADU) motor 2 (Upstream)
control (Phase A)
— — 10 13 PCU
ADM2B Duplex (ADU) motor 2
(Downstream side) control
signal (Phase B)
Duplex (ADU) motor 2 (Upstream)
control (Phase B)
— — 10 15 PCU
ADM2XA Duplex (ADU) motor 2
(Downstream side) control
signal (Phase /A)
Duplex (ADU) motor 2 (Upstream)
control (Phase /A)
— — 10 14 PCU
ADM2XB Duplex (ADU) motor 2
(Downstream side) control
signal (Phase /B)
Duplex (ADU) motor 2 (Upstream)
control (Phase /B)
— — 10 16 PCU
AINPD Duplex (ADU) paper entry
detection signal
Duplex (ADU) paper entry
detection, detection of paper exit to
finisher
Paper pass — 7 28 PCU
APPD1 Duplex (ADU) paper pass
detection signal 1
Duplex (ADU) upstream paper
pass detection
Paper pass — 7 24 PCU
APPD2 Duplex (ADU) paper pass
detection signal 2
Duplex (ADU) midstream paper
pass detection
Paper pass — 7 26 PCU
AUD Auditor installation detection
signal
Auditor installation detection Counter
available
55SCN
BUP-PRout Power save mode relay signal Selection of power save mode and
normal power mode
Relay OFF Relay ON 19 9 PCU
BZR Buzzer signal Key touch sound buzzer signal Ring 1 86 SCN
CA Clear all (Auditor) signal Clear all (Auditor) Clear 5 3 SCN
CCDFAN CCD fan motor control signal CCD fan motor control ON 1 17 SCN Not used.
CCFT Backlight control signal Backlight control ON 1 94 SCN
CFM-DC1 Cooling fan motor control
signal (Power source)
Power cooling fan motor control Max. force
of wind
Stop 19 3 PCU
CFM-DC2 Cooling fan motor control
signal (Power source)
Power cooling fan motor control Max. force
of wind
Stop 19 4 PCU
CFM-DV Cooling fan motor control
signal (Developing)
Developing cooling fan motor
control
Max. force
of wind
Stop 7 3 PCU
CFM-R1 Cooling fan motor control
signal (LSU/Process section)
Cooling fan motor control
(LSU, process section)
Max. force
of wind
Stop 21 3 PCU
CFM-R2 Cooling fan motor control
signal (LSU/Process section)
Cooling fan motor control
(LSU, process section)
Max. force
of wind
Stop 21 4 PCU
