Sharp MX-M620N

MX-M700N ELECTRICAL SECTION 11 – 19
CFM-R3 Cooling fan motor control
signal (LSU/Process section)
Cooling fan motor control
(LSU, process section)
Max. force
of wind
Stop 21 9 PCU
CFM-U1 Cooling fan motor control Cooling fan motor control
(LSU, process section)
Max. force
of wind
Stop 5 21 PCU
CFM-U2 Cooling fan motor control
signal (Paper exit, duplex
(ADU) section)
(Paper exit section rear side)
Paper exit, duplex (ADU) section
cooling
Max. force
of wind
Stop 5 28 PCU
CFM-U3 Cooling fan motor control
signal (Paper exit, duplex
(ADU) section) (Front surface)
Paper exit, duplex (ADU) section
cooling
Max. force
of wind
Stop 5 27 PCU
CHVACPWM High voltage control output
(Separation charger) (CHV)
Separation charger AC component
PWM control
— — 15 12 PCU
CHVACREM High voltage control output
(Separation charger) (CHV)
Separation charger AC component
ON/OFF control
ON OFF 15 13 PCU
CHV-PWM High voltage control output
(Separation charger) (CHV)
Separation charger DC component
PWM control
— — 15 10 PCU
CHV-REM High voltage control output
(Separation charger) (CHV)
Separation charger DC component
ON/OFF control
ON OFF 15 11 PCU
CISSET CIS identification signal CIS unit installation detection CIS
available
—1026SCN
CISTH CIS temperature detection
signal
CIS temperature detection — — 13 1 SCN Not used.
CL1 Scanner lamp control signal Scanner lamp control ON — 1 71 SCN
CLK_CCD1 CCD serial data clock signal
(CCD)
CD serial data output timing control
(CCD)
——162SCN
CLK_CCD2 CIS serial data clock signal
(CIS)
CIS serial data output timing
control (CIS)
——1011SCN
COPY Copy status (Auditor) Copy status signal (Auditor) Copying — 5 2 SCN
CRUCLK Communication CLK CRUM communication CLK — — 11 6 PCU
CRUSDA Communication data address
signal
CRUM communication data
address signal
——118PCU
CV_CA Clear all signal (Coin vendor) Clear all (Coin vendor) Clear — 4 6 SCN
CV_COPY Copy enable signal
(Coin vendor)
Copy enable (Coin vendor) Copy
enable
43SCN
CV_COUNT Count up signal (Coin vendor) Count-up (Coin vendor) Count UP 4 4 SCN
CV_DUPLEX Print count identification
signal (Duplex mode)
(For coin vendor)
Print count identification signal
(Duplex mode) (For coin vendor)
(Identification of single count or
double count)
Duplex
mode
48SCN
CV_SIZE0 Paper size signal 0
(Coin vendor)
Paper size 0 (Coin vendor) 4 9 SCN Refer to
the
separate
table (*2)
CV_SIZE1 Paper size signal 1
(Coin vendor)
Paper size 1 (Coin vendor) 4 10 SCN
CV_SIZE2 Paper size signal 2
(Coin vendor)
Paper size 2 (Coin vendor) 4 11 SCN
CV_SIZE3 Paper size signal 3
(Coin vendor)
Paper size 3 (Coin vendor) 4 12 SCN
CV_STAPLE Staple mode signal
(Coin vendor)
Staple mode identification
(Coin vendor)
Staple
mode
47SCN
CV_START Copy start signal
(Coin vendor)
Copy start status (Coin vendor) Copy start 4 5 SCN
DCCNT DC power control signal DC power ON/OFF OFF ON 9 – 8
19 – 24
PCU
DGS Paper exit gate solenoid
control signal
Paper exit gate control Duplex Simplex 7 27 PCU
DL Discharge lamp control signal Discharge lamp control ON OFF 8 9 PCU
DM OPC drum motor rotating
speed control signal
(ON/OFF)
OPS drum motor ON/OFF ON OFF 6 5 PCU
DMCLK OPC drum motor rotating
speed control (CLK) signal
OPC drum motor RPM control — — 6 7 PCU
DMS OPC drum marking sensor
signal
OPC drum mark detection — — 8 4 PCU
DMS-LED OPC drum marking sensor
LED control signal
OPC drum marking LED light
quantity control
——82PCU
DM-T OPC drum motor lock
detection signal
OPC drum motor lock detection Rotation Stop/Lock 6 9 PCU
DSKPFC1 Paper feed tray 3/4 paper
transport clutch control
signal 1
Paper feed tray 3/4 paper transport
control
Paper
transport
—1626PCU
DSKPFC2 Paper feed tray 3/4 paper
transport clutch control
signal 2
Paper feed tray 3/4 paper transport
control
Paper
transport
—178PCU
Signal name Name Function/Operation
Connector level Connector
No.
Pin
No.
PWB
name
Remark
“L” “H”
