3. Paper JAM code
A. Paper jam judgment conditions
JAM code Content
JAM detection method
JAM judge time
(JAMTST - JAMJD)
JAM detection timer start trigger
(JAMTST)
JAM judge dedtector
(JAMJD)
55/62 PPM
MODEL
(335mm/s)
70 PPM
MODEL
(395mm/s)
TRAY1 Tray 1 paper feed jam
(PFD2 not-reached)
T1PFC ON PFD2 ON 1608ms 1516ms
PFD2_NM1 PFD2 not-reached jam
(Tray 3 feed paper)
VPM ON (When the paper lead
edge comes to 40mm in front of the
transport roller 13, VPM turns ON.)
PFD2_NM1 541ms 480ms
PFD2_NM2 PFD2 not-reached jam
(Tray 4 feed paper)
VPM ON (When the paper lead
edge comes to 40mm in front of the
transport roller 13, VPM turns ON.)
PFD2_NM2 541ms 480ms
PFD2_NAD PFD2 not-reached jam
(ADU re-feed paper)
APPD2 ON PFD2_NAD 819ms 710ms
PPD_NMF PPD1 not-reached jam
(Manual feed tray feed paper)
MPRD2 ON PPD ON 429ms 364ms
PPD_NT1 PPD1 not-reached jam
(Tray 1 feed paper)
PFD2 ON PPD ON 352ms 298ms
PPD_NT2 PPD1 not-reached jam
(Tray 2 feed paper)
MPRD2 ON PPD ON 429ms 364ms
PPD_NM1 PPD1 not-reached jam
(Tray 3 feed paper)
PFD2 ON PPD ON 352ms 298ms
PPD_NM2 PPD1 not-reached jam
(Tray 4 feed paper)
PFD2 ON PPD ON 352ms 298ms
PPD_NLC PPD1 not-reached jam
(LCC paper feed paper)
MPRD2 ON PPD ON 429ms 364ms
PPD_NAD PPD1 not-reached jam
(ADU re-feed paper)
PFD2 ON PPD ON 352ms 298ms
POD1_N POD1 not-reached jam RRC ON POD1 ON 943ms 800ms
POD2_N POD2 not-reached jam POD1 ON POD2 ON 429ms 364ms
AINPD_N
(Saddle)
ADU paper entry sensor not-
reached jam
DGS ON (When the paper lead
edge is transported to 30mm apart
from the switchback operation
startposition.)
AINPD_ON (Saddle) 435ms 435ms
AINPD_N (Other) ADU paper entry sensor not-
reached jam
DGS ON (When the paper lead
edge is transported to 30mm apart
from the switchback operation
startposition.)
AINPD_ON (Other) 318ms 318ms
APPD1_N ADU transport sensor 1 not-
reached jam
AINPD ON APPD1ON 292ms 292ms
APPD2_N ADU transport sensor 2 not-
reached jam
APPD1 ON + 90mm APPD2 ON 375ms 375ms
DESK1 Tray 3 paper feed jam
(M1PFD not-reached)
M1PFC ON M1PFD ON 1531ms 1450ms
DESK2 Tray 4 paper feed jam
(M2PFD not-reached)
M2PFC ON M2PFD ON 1531ms 1450ms
M1PFD_N2 M1PFD not-reached jam
(Tray 4 feed paper)
M2PFD ON M1PFD ON 513ms 435ms
MPRD2_N2 MPRD2 not-reached jam
(Tray 2 feed paper)
VPM ON (When the paper lead
edge comes to 40mm in front of the
transport roller 4, VPM turns ON.)
MPRD2 ON 467ms 417ms
MPRD2_NM MPRD2 not reached jam
(Manual paper feed tray feed
paper)
VPM ON (When the paper lead
edge comes to 40mm in front of the
transport roller 4, VPM turns ON.)
MPRD2 ON 467ms 417ms
MPRD2_NL MPRD2 not-reached jam
(LCC paper feed paper)
VPM ON (When the paper lead
edge comes to 40mm in front of the
transport roller 4, VPM turns ON.)
MPRD2 ON 467ms 417ms
TRAY2 Tray 2 paper feed jam
(MPRD1 not-reached)
T2PFC ON MPRD1 ON 1519ms 1440ms
MPRD1_NM MPRD1 not-reached jam
(Manual paper feed tray feed
paper)
MPFD2 ON MPRD1 ON 564ms 478ms
MPRD1_NL MPRD1 not-reached jam
(LCC paper feed paper)
MPFD2 ON MPRD1 ON 564ms 478ms
MPFD2_NM MPFD2 not-reached jam
(Manual paper feed tray feed
paper)
MPFD1 ON MPFD2 ON 570ms 483ms
MPFD2_NL MPFD2 not-reached jam
(LCC paper feed paper)
LPPD ON MPFD2 ON 677ms 574ms
BPT Manual tray feed jam
(MPFD1 not-reached)
MPFC ON MPFD1 ON 1367ms 1311ms
LPPD_N LPPD not-reached jam LTD ON (LCC) LPPD ON 1447ms 1379ms
