Sharp MX-M620N

MX-M700N OTHERS 12 – 11
PFD2_ST1 PFD2 remaining jam
(Tray 1 feed paper)
RRC ON PFD2 OFF
(PFD2 paper rear
edge detection) + 65mm
PFD2 OFF
(PFD2 paper rear
edge detection)
+ 65mm
PFD2_SM1 PFD2 remaining jam
(Tray 3 feed paper)
M1PFD OFF (When paper is
transported by 50mm from M1PFD
paper rear edge detection.)
PFD2 OFF 671ms 569ms
PFD2_SM2 PFD2 remaining jam
(Tray 4 feed paper)
M1PFD OFF (When paper is
transported by 50mm from M1PFD
paper rear edge detection.)
PFD2 OFF 671ms 569ms
PFD2_SAD PFD2 remaining jam
(ADU re-feed paper)
RRC ON PFD2 OFF
(PFD2 paper rear
edge detection) + 65mm
PFD2 OFF
(PFD2 paper rear
edge detection)
+ 65mm
PPD_ST1 PPD1 remaining jam
(Tray 1 feed paper)
PFD2 OFF PPD OFF 352ms 298ms
PPD_ST2 PPD1 remaining jam
(Tray 2 feed paper)
MPRD2 OFF PPD OFF 429ms 364ms
PPD_SM1 PPD1 remaining jam
(Tray 3 feed paper)
PFD2 OFF PPD OFF 352ms 298ms
PPD_SM2 PPD1 remaining jam
(Tray 4 feed paper)
PFD2 OFF PPD OFF 352ms 298ms
PPD_SLC PPD1 remaining jam
(LCC paper feed paper)
MPRD2 OFF PPD OFF 429ms 364ms
PPD_SAD PPD1 remaining jam
(ADU re-feed paper)
PFD2 OFF PPD OFF 352ms 298ms
PPD_SMF PPD1 remaining jam
(Manual feed tray feed paper)
MPRD2 OFF PPD OFF 429ms 364ms
POD1_S
(Right paper exit,
infinite form)
POD2 not-reached jam PPD OFF POD1 OFF 1128ms 956ms
POD1_S
(Left paper exit)
POD2 not-reached jam PPD OFF POD1 OFF 1128ms 956ms
POD2_SR POD2 remaining jam
(When paper is discharged on
the right side of the machine.)
POD1 OFF POD2 OFF 429ms 364ms
POD2_SL POD2 remaining jam
(When paper is discharged on
the left side of the machine.)
POM1 ON (Switchback start) POD2 OFF Paper length + 115mm
AINPD_S (Saddle
paper exit)
ADU paper entry sensor
remaining jam
POD2 OFF AINPD OFF 187ms 187ms
AINPD_S (Other) ADU paper entry sensor
remaining jam
POD2 OFF AINPD OFF 187ms 187ms
APPD1_S ADU transport sensor 1
remaining jam
AINPD OFF APPD1 OFF 292ms 292ms
APPD2_S ADU transport sensor 2
remaining jam
LD ON APPD2 OFF
(APPD2 paper rear
edge detection) + 65mm
APPD2 OFF
(APPD2 paper rear
edge detection)
+ 65mm
M1PFD_S1 M1PFD remaining jam
(Tray 3 feed paper)
M1PFD ON M1PFD OFF Paper length
+ 65mm
M1PFD_S2 M1PFD remaining jam
(Tray 4 feed paper)
M2PFD OFF M1PFD OFF 513ms 435ms
M2PFD_S M2PFD remaining jam M2PFD ON M2PFD OFF Paper length
+ 65mm
MPRD2_S2 MPRD2 remaining jam
(Tray 2 feed paper)
MPRD1 OFF MPRD2 OFF 653ms 554ms
MPRD2_SM MPRD2 remaining jam
(Manual paper feed tray feed
paper)
MPRD1 OFF MPRD2 OFF 653ms 554ms
MPRD2_SL MPRD2 remaining jam
(LCC paper feed paper)
MPRD1 OFF MPRD2 OFF 653ms 554ms
MPRD1_S2 MPRD1 remaining jam
(Tray 2 feed paper)
MPRD1 ON MPRD1 OFF Paper length
+ 65mm
MPRD1_SM MPRD1 remaining jam
(Manual paper feed tray feed
paper)
MPFD2 OFF MPRD1 OFF 564ms 478ms
MPRD1_SL MPRD1 remaining jam
(LCC paper feed paper)
MPFD2 OFF MPRD1 OFF 564ms 478ms
MPFD2_SM MPFD2 remaining jam
(Manual paper feed tray feed
paper)
MPFD1 OFF MPFD2 OFF 570ms 483ms
JAM code Content
JAM detection method
JAM judge time
(JAMTST - JAMJD)
JAM detection timer start trigger
(JAMTST)
JAM judge dedtector
(JAMJD)
55/62 PPM
MODEL
(335mm/s)
70 PPM
MODEL
(395mm/s)
