CHAPTER VI
COMPONENT REPLACEMENT AND ADJUSTMENT PROCEDURE
WARNING: to avoid possible exposure to microwave
-
2. There is a broken door hinge or support.
energy;
3. The door gasket or seal is damaged.
A.
Before operating the oven;
4. The door is bent or warped.
1. Make sure that unlatching the door slowly is
ac-
5. There is any defective parts in the interlock, oven
companied
by a click indicating actuation of the latch
door or microwave generating and transmission
switches.
assembly.
2. Check visually the door seal for arcing and damage.
B. Do not operate the oven until after repair if any of the
following conditions exist;
1. Door does not close firmly against the front of
appliance.
6. There is any other visible damage to the oven.
C. Do not operate the oven;
1.
Without the RF gasket.
2. If the waveguide and oven cavity are not intact.
3. If the door is not closed.
OUTER
MAINS SUPPLY
CORE
BASE CABINET
DOOR
SWIN
HIGH VOLTAGE
n
wKRECTIFIER
8
AJ
POkER
TRANSFORMER
CHASSIS
\
HEATER RELAY
Figure 29.
Outer Case and Chassis Components
98
