26
STATUS INDICATORS
MISFEED REMOVAL
Misfeed in the duplex module
●
The duplex module is optional.
NOTE:
If any other misfeed locations are indicated, be sure to remove any
misfed paper from these locations before performing the procedure
described below. If not, a sheet of paper in another location may
become torn and difficult to remove.
1
Pull out the duplex module.
2
Lift up the upper and lower paper guides, and remove
the misfed paper.
●
When a misfeed occurs between the paper guides, open the
upper paper guide and remove the misfed paper.
3
Close the paper guides and push back the duplex
module.
●
Confirm that the indicator has gone out.
Misfeed removal
Paper guides
Upper paper guide
