Sharp UP-600 - Correction After Transaction Finalization

61
■ Validation slip specification
Make validation slips according to the following specification. The use of any slips other than specified
causes the printer to malfunction.
• Type of paper: plain paper
• Paper thickness: 0.0028 to 0.0055 in. (0.07 to 0.14 mm) thick
• Paper width: over 5.12 in. (130 mm)
• Print position
3.43 in.
(87 mm)
0.79 in.
(20 mm)
0.87 in.
(22 mm)
over 5.12 in. (130 mm)
over 2.76 in.
(70 mm)
Server Arrival/Departure Time Printing
Your POS terminal allows the server to print the employee arrival and departure times, etc. using the
validation printing function.
1. Turn the mode switch to the REG position.
2. Put a card into the paper chute and perform the following key operation.
• Arrival time (printed on the receipt)
Numeric key 1 →
PRINT
• Departure time (printed on the journal)
Numeric key 2 →
PRINT
3. Sample printout
Arrival time
(on the receipt)
Server code
Departure time
(on the journal)
